Multi9 - C60H - MCB - 3P - 10 A - C Curve - 415 V - 15 kA

Multi9 - C60H - MCB - 3P - 10 A - C Curve - 415 V - 15 kA

SQDM9F14310 M9F14310 785901755746
387.72 / EA
  • Amperage: 10 A
  • Certifications: CCC, EAC
  • Country of Origin: France
  • Depth: 2.83 in, 72 mm
  • Height: 3.19 in, 81 mm
  • Mounting Type: Clip-On
  • Standard: EN/IEC 60947-2
  • Strip Length: 0.55 in, 14 mm
  • Voltage: 125 V, 240 V, 415 V, 440 V
  • Weight: 0.36 kg, 0.79 lb
  • Width: 2.13 in, 54 mm
This Multi9 C60H is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 10A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 15kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
  • Product Description
  • Specifications
This Multi9 C60H is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 10A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 15kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
  • Complementary
    • Colour : Gray
    • Mechanical Durability : 20000 cycles
    • Provision For Padlocking : Padlockable
    • Uimp Rated Imp Wstd Voltage : 6 kVEN/IEC 60947-2
    • Ue Rated Operational Voltage : 240 V AC 50/60 Hz between phases || 415 V AC 50/60 Hz between phases || 440 V AC 50/60 Hz between phases || <= 125 V DC
    • Wire Stripping Length : 0.55 in (14 mm) top or bottom
    • 9 mm Pitches : 6
    • Width : 2.13 in (54 mm)
    • Ics Rated Service Breaking Cap : 15 kA 50 % EN/IEC 60947-2 - 240 V AC 50/60 Hz || 7.5 kA 50 % EN/IEC 60947-2 - 415 V AC 50/60 Hz || 5 kA 50 % EN/IEC 60947-2 - 440 V AC 50/60 Hz || 40 kA 100 % EN/IEC 60947-2 - <= 125 V DC
    • Depth : 2.83 in (72 mm)
    • Earth-Leakage Protection : Separate block
    • Electrical Durability : 10000 cycles
    • Height : 3.19 in (81 mm)
    • Tightening Torque : 17.70 lbf.in (2 N.m) top or bottom
    • Magnetic Tripping Limit : 8.5 x In +/- 20 % AC || 12 x In +/- 20 % DC
    • Connections - Terminals : Tunnel type terminal top or bottom) 0.00…0.04 in² (1…25 mm²) - rigid || Tunnel type terminal top or bottom) 0.00…0.04 in² (1…25 mm²) - flexible || Tunnel type terminal top or bottom) 0.00…0.04 in² (1…25 mm²) - flexible with ferrule
    • Contact Position Indicator : Yes
    • Network Frequency : 50/60 Hz
    • Mounting Support : DIN rail
    • Mounting Mode : Clip-on
    • Control Type : Toggle
    • Local Signalling : ON/OFF indication
    • Product Weight : 0.79 lb(US) (0.36 kg)
    • Ui Rated Insulation Voltage : 500 V AC 50/60 Hz EN/IEC 60947-2
  • Main
    • Range : Multi 9
    • Breaking Capacity : 40 kA Icu <= 125 V DC EN/IEC 60947-2 || 30 kA Icu 240 V AC 50/60 Hz between phases EN/IEC 60947-2 || 15 kA Icu 415 V AC 50/60 Hz between phases EN/IEC 60947-2 || 10 kA Icu 440 V AC 50/60 Hz between phases EN/IEC 60947-2
    • Suitability For ISOlation : Yes conforming to EN/IEC 60947-2
    • Standards : EN/IEC 60947-2
    • Product Name : Multi 9 C60
    • Number Of Protected Poles : 3
    • Curve Code : C
    • Product Or Component Type : Miniature circuit-breaker
    • In Rated Current : 10 A 122 °F (50 °C) EN/IEC 60947-2
    • Device Short Name : C60H
    • Device Application : Distribution
    • Poles Description : 3P
    • Trip Unit Technology : Thermal-magnetic
    • Product Certifications : EAC || CCC
    • Utilisation Category : Category A EN/IEC 60947-2
    • Network Type : DC || AC
  • Offer Sustainability
    • Mercury Free : Yes
    • WEEE : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • Halogen Content Performance : Halogen free plastic parts & cables product
    • Green Premium Status : Green Premium product
    • EU RoHs Directive : Compliant
  • Environment
    • Pollution Degree : 3 EN/IEC 60947-2
    • IP Degree Of Protection : IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529
    • Ambient Air Temp For Op : -22…158 °F (-30…70 °C)
    • Ambient Air Temp For Storage : -40…176 °F (-40…80 °C)
    • Heat Dissipation : 5.4 W 415 V - 10 A
    • Overvoltage Category : IV
    • Relative Humidity : 95 % 131 °F (55 °C)
    • Tropicalisation : 2 conforming to IEC 60068-1
  • Ordering And Shipping Details
    • Nbr. Of Units In Pkg. : 1
    • Discount Schedule : DE2
    • GTIN : 00785901755746
    • Returnability : No
    • Category : 00908 - C60N SUPPLEMENTARY PROTECTORS
    • Country Of Origin : FR
