Modicon Momentum - high speed counter module base - 6 I / 4 O

HIGH SPEED COUNTER BASE

SQD170AEC92000 170AEC92000 3595861147744
1533.88 / EA
http://schema.org/OutOfStock
Mayer-DDS-Modicon Momentum - high speed counter module base - 6 I / 4 O-1
  • Warranty Length: 18 mth
This counter module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This high speed counter module base has 2 groups of 3 discrete inputs and 2 groups of 2 discrete outputs with positive discrete input logic. It is a module with discrete input voltage ranges from -3V DC to 30V DC, 24V DC and discrete output voltage of 24V. It is furnished with 2 removable terminal blocks for electrical connection. It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
QTY
  • Product Description
  • Features
  • Specifications
This counter module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This high speed counter module base has 2 groups of 3 discrete inputs and 2 groups of 2 discrete outputs with positive discrete input logic. It is a module with discrete input voltage ranges from -3V DC to 30V DC, 24V DC and discrete output voltage of 24V. It is furnished with 2 removable terminal blocks for electrical connection. It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Complementary Attributes
    • Maximum Leakage Current : 1 mA DC 24 V, 1 mA DC 24 V, 1 mA DC 24 V
    • Maximum Voltage Drop : <0.5 V 0.5 A at state on, <0.5 V 0.5 A at state on, <0.5 V 0.5 A at state on
  • Important Information Attributes
    • Counting Frequency : 10 kHz single ended, 10 kHz single ended, 200 kHz differential, 200 kHz differential
    • Current Consumption : 280 mA 24 V DC, 280 mA 24 V DC, 280 mA 24 V DC
    • Electrical Connection : 2 connectors for removable terminal blocks, 2 connectors for removable terminal blocks
    • Resistance To Electromagnetic Fields : 10 V/m 80...1000 MHz IEC 801-3, 10 V/m 80...1000 MHz IEC 801-3, 10 V/m 80...1000 MHz IEC 801-3
    • Resistance To Electrostatic Discharge : 4 kV contact IEC 801-2, 4 kV contact IEC 801-2, 4 kV contact IEC 801-2, 8 kV on air IEC 801-2, 8 kV on air IEC 801-2, 8 kV on air IEC 801-2
    • Response Time : < 0.1 ms from state 0 to state 1 output circuit, < 0.1 ms from state 0 to state 1 output circuit, < 0.1 ms from state 0 to state 1 output circuit, < 0.1 ms from state 1 to state 0 output circuit, < 0.1 ms from state 1 to state 0 output circuit, < 0.1 ms from state 1 to state 0 output circuit, 3 ms from state 0 to state 1 input circuit, 3 ms from state 0 to state 1 input circuit, 3 ms from state 0 to state 1 input circuit, 3 ms from state 1 to state 0 input circuit, 3 ms from state 1 to state 0 input circuit, 3 ms from state 1 to state 0 input circuit
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-07-10
    • Device Type : PLC System - PLC Component
    • Serviceability : No
    • Traceability : Yes
    • Field Service Division : IDIBS
    • Average Life Duration : 15 year(s)
    • Legacy WEEE Scope : Out
    • Scope Perimeter : At least in Europe
    • EOLI Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI1403005EN
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : Yes
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • WD Status : 1 - GSC certified
    • Counter Configuration : via comm adapter
    • Package Weight Lbs : 356.000 g
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : high speed counter module base
    • Range Of Product : Modicon Momentum automation platform
    • Returnability : No
    • Sustainable Packaging : No
    • Pep Code : ENVPEP1403005EN
    • Product Kit Identifier : N
  • Environment Attributes Main
    • EU ROHS Directive : Compliant By Exemption​, Pro-active compliance (Product out of EU RoHS legal scope)
    • Relative Humidity : 95-95 % without condensation, 95-95 % without condensation
    • ROHS Exemption Information : Yes
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : X
    • Mercury Free : Yes
    • Circularity Profile : ENVEOLI1403005EN
    • Environmental Disclosure : ENVPEP1403005EN
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP1403005EN
  • General Attributes
    • Product Or Component Type : high speed counter module base
    • Range Of Product : Modicon Momentum automation platform
  • Output Attributes
    • Discrete Output Current : 1 A per counter, 1 A per counter, 2 A per module, 2 A per module, 0.5 A per point, 0.5 A per point
    • Discrete Output Voltage : 24 V
  • Surge Protection And Filtering Attributes
    • Surge Current : 5 A 1 ms, 5 A 1 ms
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Input Attributes
    • Counting Input Type : absolute SSI up, down with 4 sub-modes, absolute SSI up, down with 4 sub-modes, incremental up, down, quadrature, incremental up, down, quadrature
    • Counting Input Voltage : 24 V single ended, 24 V single ended, 5 V differential, 5 V differential
    • Discrete Input Voltage : - 3...30 V DC, - 3...30 V DC, 24 V DC, 24 V DC
    • Input Overvoltage Protection : 45-45 V 10 s, 45-45 V 10 s
    • Counter Inputs Resolution : 24 bits + sign
