This Harmony XB4 illuminated double head has 1 green, 1 red button and 1 central white pilot light, operates with a spring return / impulse mechanism. It has a metal bezel. It is marked with "I" and "O" symbols. This double-head button provides a complete 2 button interface to your machines with a single panel cut-out. It is easily installed into a standard 22mm diameter cut-outs and connected with simple screw-clamp connections. Its schematic is clearly distinguishable thanks to illuminated clear colors and markings, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66/IP67/IP69/IP69K and IP69K, making it ideal for operation in harsh environments.

• Environment
• Product Certifications : GL || BV || DNV || LROS (Lloyds register of shipping) || UL Listed || CSA
• Ik Degree Of Protection : IK06 conforming to IEC 50102
• Ambient Air Temperature For Operation : -40-70 °C
• Resistance To Electromagnetic Fields : 10 V/m IEC 61000-4-3
• Standards : IEC 60947-5-5 || CSA C22.2 No 14 || IEC 60947-5-1 || UL 508 || IEC 60947-1 || IEC 60947-5-4 || JIS C8201-5-1 || JIS C8201-1
• Shock Resistance : 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
• Vibration Resistance : 5 gn 2-500 Hz)IEC 60068-2-6
• Ip Degree Of Protection : IP66 IEC 60529 || IP69K IEC 60529 || IP69 IEC 60529
• Ambient Air Temperature For Storage : -40-70 °C
• Nema Degree Of Protection : NEMA 13 || NEMA 4X
• Resistance To Electrostatic Discharge : 6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
• Electrical Shock Protection Class : class I IEC 60536
• Protective Treatment : TH
• Resistance To Fast Transients : 2 kV IEC 61000-4-4
• Electromagnetic Emission : class B IEC 55011
• Contractual warranty
• Warranty : 18 months
• Offer Sustainability
• Rohs Exemption Information : Yes
• Mercury Free : Yes
• Environmental Disclosure : ENVPEP1808008EN
• Sustainable Offer Status : Green Premium product
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• China Rohs Regulation : X
• Circularity Profile : ENVEOLI1808008EN
• Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
• Important Information
• Important Message : A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
• Complementary
• Contacts Usage : standard contacts
• Operating Force : 3.5 N NC changing electrical state || 3.8 N NO changing electrical state
• Short-Circuit Protection : 10 A cartridge fuse gG IEC 60947-5-1
• Operating Travel : 1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
• Contacts Material : silver alloy (Ag/Ni)
• Positive Opening : with IEC 60947-5-1 appendix K
• Type Of Operator : spring return
• Operators Description : green ''I'' - red ''O''
• [Ith] Conventional Free Air Thermal Current : 10 A IEC 60947-5-1
• Shape Of Signaling Unit Head : rectangular
• Net Weight : 0.13 kg
• [Uimp] Rated Impulse Withstand Voltage : 6 kV IEC 60947-1
• Current Consumption : 14 mA
• Fixing Collar Material : zamak
• Operator Profile : 1 flush - 1 projecting push-buttons - 1 central pilot light
• Resistance To High Pressure Washer : 7000000 Pa 55 °C 0.1 m
• Electrical Durability : 1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
• Connections - Terminals : screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1
• Contacts Type And Composition : 1 NO + 1 NC
• Service Life : 100000 h at rated voltage and 25 °C
• Surge Withstand : 1 kV IEC 61000-4-5
• [Ui] Rated Insulation Voltage : 600 V 3)IEC 60947-1
• Signalling Type : steady
• [Ie] Rated Operational Current : 3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
• Contact Operation : slow-break
• Operator Profile : green flush, I white) || red projecting, O white)
• Mechanical Durability : 1000000 cycles
• Compatibility Code : XB4
• Electrical Reliability : λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
• Tightening Torque : 0.8-1.2 N.m IEC 60947-1
• Shape Of Screw Head : cross JIS No 1 || cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
• [Us] Rated Supply Voltage : 110...120 V AC 50/60 Hz
• Bulb Base : integral LED
• Specifications
• Range Of Product : Harmony XB4
• Light Source : protected LED
• Mounting Diameter : 22 mm
• Product Or Component Type : illuminated double-headed push-button
• Colour Of Marking : white marking when green, red or black caps || black marking when white caps
• Head Type : standard
• Device Presentation : complete product
• Bezel Material : chromium plated metal
• Light Source Colour : white
• Device Short Name : XB4
