This product is part of the Modicon M340 range, an offer of Programmable Automation Controllers (PAC). This backplane expander is an extension accessory of Modicon M580 and M340 Programmable Automation Controllers (PAC). It is an Ethernet backplane rack with a current of 160mA at 24V DC and 22mA at 3.3V DC. This product is robust, high quality and based on the latest innovative technology. It is furnished with 2 x 9-way SUB-D female connectors for electrical connection. It is an IP20 rated product. It is suitable for medium to large process applications and expander is It is suitable for multiracks configuration. It meets EN 61131-2, EN 61000-6-4, EN 61000-6-2 and EN 61010-2-201 standards. This backplane expander is compatible with Modicon M340 BMXXBP0600, BMXXBP0400, BMXXBP0800 and BMXXBP1200 backplane. Modicon X80 consists in a compatible modules common platform that reduce maintenance and training costs with same spare parts in stock, and unique training for different Programmable Automation Controllers (PAC).

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Important Information Attributes
• Persona Type Ids : EU, OM8, SI
• Persona Type Names : End User, OEM - Control Panelbuilder, System Integrator
• Current Consumption : 160 mA 24 V DC, 22 mA 3.3 V DC
• Local Signalling : 1 LED green operating status (RUN) bus, 1 LED red collision error (COL) rack, 4 LEDs green rack adresses status
• Carbon Footprint Of The Distribution Phase A4 : 0.022492, 0 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4 : 0.4 kg CO2 eq., 0.35883
• Carbon Footprint Of The Installation Phase A5 : 0.034196, 0 kg CO2 eq.
• Carbon Footprint Of The Manufacturing Phase A1 To A3 : 5 kg CO2 eq., 5.3489
• Carbon Footprint Of The Use Phase B2 B3 B4 B6 : 185 kg CO2 eq., 185.3
• Certificate Agency : CE, UL, CSA, RCM, EAC, Merchant Navy
• Local Data Status : Publishable
• Local Publishable Date : 2026-01-12
• Return Indicator : Y
• Stocking Flag : N
• Stock Policy : 2
• Device Type : PLC System - PLC Component
• Serviceability : No
• Traceability : Yes
• Field Service Division : IDIBS
• Average Life Duration : 20 year(s)
• Manufacturing Carbon Footprint : 5.3489
• Use Carbon Footprint : 185.3
• Weee Scope : Out
• Scope Perimeter : At least in Europe
• Eoli Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI2310002EN
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• Rohs Eur In Scope : No
• Rohs Eur Status : Compliant By Exemption
• Rohs Eur Conformity Date : 2438
• Rohs Eur Full Compliance Status : Compliant By Exemption
• China Rohs In Scope : Yes
• China Rohs Label : 5
• With Recycled Cardboard : Yes
• Without Single Use Plastic : Yes
• Product Contributes To Saved And Avoided Emissions : No
• Tier Id : 1
• Tier : 1
• Function Option Id : STANDARD
• Function Option : Standard
• Market Segmentation Id : INDUSTRIAL
• Market Segmentation : Industrial
• Product Kit Identifier : N
• Electrical Connection : 2 female connectors SUB-D 9
• Environmental Characteristic : hazardous location class I division 2
• Module Format : standard
• Product Availability : Stock - Normally stocked in distribution facility
• Protective Treatment : TC
• Range Of Product : Modicon M340 automation platform
• Returnability : Yes
• Software Version : v5.9.4
• Sustainable Packaging : Yes
• Total Lifecycle Carbon Footprint : 191 kg CO2 eq.
• Accessory Separate Part Category : extension accessory
• Accessory Separate Part Destination : for multiracks configuration
• Accessory Separate Part Type : backplane
• Accessory Separate Part Designation : backplane expander
• Warranty In Months : 18
• Pep Code : ENVPEP2310002EN
• Database Version : 2022-01
• Pep Verification Date : 2023-11-01
• Pcr Version : PEP-PCR-ed4-2021 09 06
• Psr Version : PSR-0005-ed2-2016 03 29
• Type Of Verification For The Pep : Independent internal review
• Data Source : referent product
• Functional-unit Description : The X-Bus Rack Expansion Module has a long life cycle for about more than 10 years with a 100% use rate. Typical electrical power is 4W (160 mA at 24 V DC).& 10& 10IP degree of protection: IP20& 10IEC 61000-6-5, IEC 61850-3,UL 61010-2-201& 10CSA C22.2 No 61010-2-201
• Functional-unit Quantity : 1
• Functional-unit Unit : Unit
• Reference Lifetime, In Y : 10
• Energy Consumption On Product Lifetime, In Kwh : 315.36
• Energy Model - Manufacturing [A1-a3] : Energy model used: Electricity Mix; Production mix; Low voltage; FR
• Energy Model - Installation [A5] : Electricity Mix; Production mix; Low voltage; US / Electricity Mix; Production mix; Low voltage; UE-27 / Electricity Mix; Production mix; Low voltage; APAC
• Energy Model - Use [B6] : Electricity Mix; Production mix; Low voltage; US / Electricity Mix; Production mix; Low voltage; UE-27 / Electricity Mix; Production mix; Low voltage; APAC
• Energy Model - End Of Life [C1-c4] : Electricity Mix; Production mix; Low voltage; US / Electricity Mix; Production mix; Low voltage; UE-27 / Electricity Mix; Production mix; Low voltage; APAC
• Recyclability Potential, In % : 26
• Offer Owner Code : 190786
• Pn : 1
• Acidification (Ap) (Mole Of H+ Equiv) Operational Energy Use [B6] : 1.1251
• Climate Change - Fossil Fuels ( Kg Co2 Eq.) Manufacturing [A1-a3] : 5.339
• Climate Change - Fossil Fuels ( Kg Co2 Eq.) Operational Energy Use [B6] : 185.15
• Climate Change - Total ( Kg Co2 Eq.) Manufacturing [A1-a3] : 5.3489
• Climate Change - Total ( Kg Co2 Eq.) Operational Energy Use [B6] : 185.3
• Depletion Of Abiotic Resources - Fossil Fuels (Mj) Manufacturing [A1-a3] : 69.96
• Depletion Of Abiotic Resources - Fossil Fuels (Mj) Operational Energy Use [B6] : 3684.7
• Depletion Of Abiotic Resources - Fossil Fuels (Mj) End Of Life [C1-c4] : 9.2839
• Depletion Of Abiotic Resources - Fossil Fuels (Mj) Benefits/Loads Beyond System Boundaries [D] : -3.48
• Ecotoxicity (Fresh Water) (Ctue) Manufacturing [A1-a3] : 77.846
• Ecotoxicity (Fresh Water) (Ctue) Operational Energy Use [B6] : 2551.3
• Ecotoxicity (Fresh Water) (Ctue) End Of Life [C1-c4] : 69.377
• Ecotoxicity (Fresh Water) (Ctue) Benefits/Loads Beyond System Boundaries [D] : -2.5689
• Hazardous Waste Disposed Of (Kg) Manufacturing [A1-a3] : 14.575
• Hazardous Waste Disposed Of (Kg) Operational Energy Use [B6] : 4.1759
• Hazardous Waste Disposed Of (Kg) Benefits/Loads Beyond System Boundaries [D] : -3.7582
• Impacts Related To Land Use/Soil Quality (-) Total Life Cycle : 2450967
• Impacts Related To Land Use/Soil Quality (-) Operational Energy Use [B6] : 20456
• Ionizing Radiation, Human Health (Kbq Of U235 Equiv.) Total Life Cycle : 1511334
• Ionizing Radiation, Human Health (Kbq Of U235 Equiv.) Manufacturing [A1-a3] : 29037
• Ionizing Radiation, Human Health (Kbq Of U235 Equiv.) Operational Energy Use [B6] : 122.09
• Net Use Of Fresh Water (M3) Total Life Cycle : 1121757
• Net Use Of Fresh Water (M3) End Of Life [C1-c4] : 0.9261
• Non-hazardous Waste Disposed Of (Kg) Total Life Cycle : 3091633
• Non-hazardous Waste Disposed Of (Kg) Manufacturing [A1-a3] : 22553
• Non-hazardous Waste Disposed Of (Kg) Operational Energy Use [B6] : 28569
• Terrestrial Eutrophication (Mole Of N Equiv) Total Life Cycle : 1604285
• Terrestrial Eutrophication (Mole Of N Equiv) Operational Energy Use [B6] : 15541
• Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Total Life Cycle : 3764294
• Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Manufacturing [A1-a3] : 69.96
• Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6] : 3684.7
• Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) End Of Life [C1-c4] : 92839
• Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Benefits/Loads Beyond System Boundaries [D] : -3.48
• Total Use Of Primary Energy During The Life Cycle (Mj) Total Life Cycle : 4253039
• Total Use Of Primary Energy During The Life Cycle (Mj) Manufacturing [A1-a3] : 71949
• Total Use Of Primary Energy During The Life Cycle (Mj) Operational Energy Use [B6] : 4171.3
• Total Use Of Primary Energy During The Life Cycle (Mj) End Of Life [C1-c4] : 94383
• Total Use Of Primary Energy During The Life Cycle (Mj) Benefits/Loads Beyond System Boundaries [D] : -35075
• Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Total Life Cycle : 4887347
• Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Manufacturing [A1-a3] : 1989
• Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6] : 486.59
• Use Of Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Total Life Cycle : 25665
• Use Of Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Manufacturing [A1-a3] : 25665
• Use Of Non-renewable Primary Energy, Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Total Life Cycle : 3761728
• Use Of Non-renewable Primary Energy, Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Manufacturing [A1-a3] : 67394
• Use Of Non-renewable Primary Energy, Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6] : 3684.7
• Use Of Non-renewable Primary Energy, Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) End Of Life [C1-c4] : 92839
• Use Of Non-renewable Primary Energy, Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Benefits/Loads Beyond System Boundaries [D] : -3.48
• Use Of Renewable Primary Energy, Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Total Life Cycle : 4881586
• Use Of Renewable Primary Energy, Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Manufacturing [A1-a3] : 14129
• Use Of Renewable Primary Energy, Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6] : 486.59
• Environment Attributes Main
• Directives : 2014/35/EU - low voltage directive, 2014/30/EU - electromagnetic compatibility
• Product Compatibility : BMXXBP0600, BMXXBP0400, BMXXBP0800, BMXXBP1200
• Take Back : No
• Recycled Metal Content At Cr Level : 0 %
• China Rohs Regulation : X
• Mercury Free : Yes
• Carbon Footprint : 191.064418
• Ambient Air Temperature For Operation : 0-60 °C
• Circularity Profile : ENVEOLI2310002EN
• Environmental Disclosure : ENVPEP2310002EN
• Eu Rohs Directive : Compliant By Exemption
• Ip Degree Of Protection : IP20
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : Yes
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Relative Humidity : 10-95 % without condensation
• Pep Code : ENVPEP2310002EN
• Pep Verification Date : 2023-11-01
• Pcr Version : PEP-PCR-ed4-2021 09 06
• Psr Version : PSR-0005-ed2-2016 03 29
• Type Of Verification For The Pep : Independent internal review
• General Attributes
• Range Of Product : Modicon M340 automation platform
• ETIM
• ETIM 8 : EC000810
• ETIM 9 : EC000810
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Country of Origin : France, United States
