Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 220-240V

Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 220-240V

SQD9001SKT7 9001SKT7 785901837268
342.08 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 220-240V-1
  • Bezel Material: Plastic
  • Light Source: Incandescent Bulb, Incandescent
  • Operating Position: Any Position
  • Warranty Length: 18 mth
QTY
  • Features
  • Specifications
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Physical Attributes
    • Cad Overall Depth : 42 mm
    • Cad Overall Height : 70 mm
    • Cad Overall Width : 54 mm
    • Cap Operator Or Lens Color : without cap
    • Size : 30 mm
  • Conformance Attributes
    • Product Certifications : UL 508, NEMA
    • Standards : JIS C8201-5-1, IEC 60947-5-4, IEC 60947-1, CSA C22.2 No 14, JIS C 852, UL 508, IEC 60947-5-1, JIS C8201-1
  • Important Information Attributes
    • Persona Type Ids : BM9, EU, LC, OM, OM8, PB, SC, SI, VR
    • Persona Type Names : Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
    • Market Segmentation Id : COMMERCIAL, INDUSTRIAL
    • Market Segmentation : Commercial, Industrial
    • Customizable : 1, no
    • Light Block Supply : via integral transformer, via integral transformer 220...240 V AC 50/60 Hz 6 V)
    • Light Source : incandescent bulb, incandescent
    • Us Rated Supply Voltage2 : 220...240 V, 220...240 V AC 50/60 Hz
    • Local Data Status : Publishable
    • Local Publishable Date : 2026-01-12
    • Legacy WEEE Scope : In
    • Scope Perimeter : Outside of Europe
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : Yes
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Bezel Material : plastic
    • Bulb Base : BA 9s
    • Cap Operator Or Lens Color : without cap
    • Compatibility Code : 9001SK
    • Contacts Type And Composition : 1 C/O
    • Device Short Name : 9001SK
    • Electrical Shock Protection Class : class II conforming to IEC 61140
    • Mounting Diameter : 30 mm
    • Operating Mode : push-to-test
    • Operating Position : any position
    • Package Weight Lbs : 226.796 g
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : head for push-to-test pilot light
    • Protective Treatment : TC
    • Range Of Product : Harmony 9001SK
    • Returnability : No
    • Shape Of Screw Head : cross slotted
    • Shape Of Signaling Unit Head : round
    • Shock Resistance : 50 gn IEC 60068-2-27
    • Short Circuit Protection : 10 A cartridge fuse IEC 60947-5-1
    • Supply Frequency : 50...60 Hz
    • Sustainable Packaging : Yes
    • Tightening Torque : 0.8-0.8 N.m IEC 60947-1
    • Vibration Resistance : 7 gn (f= 2-500 Hz) conforming to IEC 60068-2-6
    • Ith Conventional Free Air Thermal Current2 : 10 A
    • Ui Rated Insulation Voltage2 : 250 V 2)IEC 60947-1
    • Uimp Rated Impulse Withstand Voltage2 : 2.5 kV IEC 60947-1
    • Connections Terminals : screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
    • Medium Desc : Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 220-240V
    • Stocking Flag : Y
    • Product Kit Identifier : N
    • Global Commercial Status : Commercialised
    • Connections Terminals3 : screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
    • Ith Conventional Free Air Thermal Current5 : 10 A
    • Ui Rated Insulation Voltage5 : 250 V 2)IEC 60947-1
    • Uimp Rated Impulse Withstand Voltage5 : 2.5 kV IEC 60947-1
    • Us Rated Supply Voltage5 : 220...240 V AC 50/60 Hz
  • Environment Attributes Main
    • EU ROHS Directive : Compliant , Pro-active compliance (Product out of EU RoHS legal scope)
    • IP Degree Of Protection : IP66 IEC 60529, IP65/IP66
    • Nema Degree Of Protection : NEMA 1, NEMA 12, NEMA 13, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X
    • ROHS Exemption Information : Yes
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : X
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • Ambient Air Temperature For Operation : -25-70 °C
    • Ambient Air Temperature For Storage : -40-70 °C
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • General Attributes
    • Product Or Component Type : head for push-to-test pilot light
    • Range Of Product : Harmony 9001SK
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
