Internal screw-presure-plate back and side wire capability.
Two drive screws anchor strap to back body and face.
Product Line : Pass & Seymour
Color : Red
NEMA Rating : 5-20R
Special Features : Heavy-duty, brass strap for added strength and ground conductivity. .032 inch thick, brass, triple-wipe power contacts for lasting retention. Strap tabs wrap around face to prevent strap from separating from face and back body. Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring. Two drive screws anchor strap to back body and face. Tri-drive brass terminal screws. Internal screw-presure-plate back and side wire capability. Two back wire holes for more wiring flexibility. Auto-ground clip assures positive ground.
Wire Size : #14 - #10
Environmental Conditions : Flammability: UL94 V2
Number of Wires : 3.0
Voltage : 125.0 V
Connection : Back and side wire
Amperage : 20 A
Number of Poles : Double Pole
Standard : UL498, CSA C22.2 No. 42
Country of Origin : MX
Dielectric Strength : Withstands 2000V minimum
Temperature Rating : Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
