PASS & SEYMOUR

Hard Use Specification Grade Switch, Gray

15A 120/277VAC B+S WIRE COMM 4

PSSCSB15AC4GRY CSB15AC4-GRY 785007126310
21.16 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Hard Use Specification Grade Switch, Gray-1
  • Amperage: 15 A
  • Applications: Commercial, Industrial
  • Country of Origin: Mexico
  • Depth: 1.073 in
  • Finish: Matte
  • Height: 2.375 in
  • Indoor/Outdoor: Indoor
  • Load Type: CFL, Fluorescent, Halogen, Incandescent, LED, Universal, Xenon
  • Material: Thermoplastic
  • Mounting Type: Wall Box
  • Number of Gangs: 1
  • Number of Poles: 4
  • Number of Switches: 1
  • Switch Type: Toggle
  • Type: Switch
  • Voltage: 120 V, 277 V
  • Warranty Length: 1 yr
  • Wattage: 4 W
  • Width: 1.32 in
Construction 4-Way Switch, Back and Side-Wire, 15A 120/277V.
QTY
  • Product Description
  • Features
  • Specifications
Construction 4-Way Switch, Back and Side-Wire, 15A 120/277V.
  • Features
    • One-piece brass alloy contact arm for reliable electrical performance.
    • One-piece steel strap with integral ground is plated for corrosion resistance.
    • High strength thermoplastic polycarbonate toggle resists breaking and chipping under heavy abuse.
    • Heavy-duty toggle bumpers for smooth and quiet operation.
    • Back body made of glass-reinforced nylon. Locking support provides resistance to face and back body separation.
    • Available with side wire or external screw-pressure-plate back and side wire models capable of accepting #14 - #10 AWG copper or copper-clad wire.
    • Cam designed for fast make with positive break action to minimize arcing and prolong switch life.
    • Oversized silver alloy contacts for longer dependable switch life.
    • Tri-drive terminal and mounting screws.
    • For covering patents, see www.legrand.us/patents.
    • For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
  • Certifications
    • cULus Listed
    • UL Listed
    • Federal Spec Listed
    • CSA Listed
  • Specifications
    • Depth : 1.073 in
    • Height : 2.375 in
    • Color : Gray
    • Width : 1.32 in
    • Finish : Matte
    • Country of Origin : Mexico
    • Material : Thermoplastic
    • Product Line : Pass & Seymour
    • Type : Switch
    • Load Type : CFL
    • Load Type : LED
    • Wattage : 4.0 W
    • Standard : UL 20
    • Amperage : 15.0 A
    • Load Type : Xenon
    • Voltage : 120 VAC
    • Voltage : 277 VAC
    • Standard : FEDSPEC
    • Load Type : Halogen
    • Number of Gangs : 1
    • Switch Type : Toggle
    • Load Type : Universal
    • Indoor/Outdoor : Indoor
    • Load Type : Fluorescent
    • Number of Poles : 4-Way
    • Load Type : Incandescent
    • Mounting Type : Wall Box
    • Number of Switches : 1.0
    • Wall Plate Included : No
    • Throw Type : Double Throw
    • Requires Neutral Wire : No
    • Application Sector : Commercial
    • Application Sector : Industrial
    • Load Rating : 15 A @ 120/277 VAC
    • Closed Contact Resistance : Toggle
    • Horsepower Rating : 2 HP @ 240 VAC
    • Connection Location : Back and Side
    • Horsepower Rating : 1/2 HP @ 120 VAC
    • Wire Connection Type : Screw Terminals
    • Warranty Type : 1-Year Limited Warranty
    • Terminal Accommodation : #14 AWG - #10 AWG
    • Features : Single Piece Plated Steel Mounting Strap
    • Special Features : High strength toggle, heavy duty toggle bumpers, locking support
