Terminal compartments isolated from each other for positive conductor containment.
For covering patents, see www.legrand.us/patents."
Connection : Back and side wire
Temperature Rating : Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
Country of Origin : MX
Number of Wires : 3.0
Environmental Conditions : Flammability: UL94 V2
Amperage : 15 A
Wire Size : #14 - #10
Number of Poles : Double Pole
Special Features : Corrosion-resistant, plated and tabbed steel strap locked in to face and back body to resist pulling away from face/body assembly. .032 inch thick, brass, triple-wipe power contacts for lasting retention. Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring. Impact-resistant nylon face. 8 hole internal screw-pressure-plate back wire terminals accept #14 – #10 AWG solid or stranded copper or copper-clad conductors. Terminal compartments isolated from each other for positive conductor containment. Tri-drive terminal and mounting screws. Auto-ground clip assures positive ground.
