Commercial 3-Way Switch, Side-Wire, 20A 120/277V.These switches offer excellent value while meeting federal specification standards. External screw-pressure-plate back wiring enables fast installation and superior electrical connections. Rugged construction shrugs off hard use and abuse.

• Features
• One-piece brass alloy contact arm for reliable electrical performance.
• One-piece steel strap with integral ground is plated for corrosion resistance.
• High strength thermoplastic polycarbonate toggle resists breaking and chipping under heavy abuse.
• Heavy-duty toggle bumpers for smooth and quiet operation.
• Back body made of glass-reinforced nylon. Locking support provides resistance to face and back body separation.
• Available with side wire or external screw-pressure-plate back and side wire models capable of accepting #14 - #10 AWG copper or copper-clad wire.
• Cam designed for fast make with positive break action to minimize arcing and prolong switch life.
• Oversized silver alloy contacts for longer dependable switch life.
• Tri-drive terminal and mounting screws.
• For covering patents, see www.legrand.us/patents.
• For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
• Certifications
• cULus Listed

• Specifications
• Depth : 1.073 in
• Height : 3.281 in
• Color : White
• Width : 1.32 in
• Finish : Matte
• Material : Thermoplastic
• Country of Origin : Mexico
• Product Line : Pass & Seymour
• Type : Switch
• Load Type : CFL
• Load Type : LED
• Amperage : 20.0 A
• Load Type : Xenon
• Voltage : 120 VAC
• Voltage : 277 VAC
• Standard : FEDSPEC
• Load Type : Halogen
• Number of Gangs : 1
• Seismic Tested : No
• Switch Type : Toggle
• Load Type : Universal
• Indoor/Outdoor : Indoor
• Load Type : Fluorescent
• Number of Poles : 3-Way
• Load Type : Incandescent
• Mounting Type : Wall Box
• Number of Switches : 1.0
• Standard : FedSpec WS896
• Standard : Standard UL20
• Wall Plate Included : No
• Throw Type : Double Throw
• Requires Neutral Wire : No
• NEMA Rating : WD-1 and WD-6
• Standard : UL Listed E140597
• Application Sector : Commercial
• Application Sector : Industrial
• Load Rating : 20 A @ 120/277 VAC
• Horsepower Rating : 1 HP @ 120 VAC
• Horsepower Rating : 2 HP @ 240 VAC
• Connection Location : Back and Side
• Standard : Flammability Rating UL94 V2
• Wire Connection Type : Screw Terminals
• Warranty Type : 1-Year Limited Warranty
• Terminal Accommodation : #14 AWG - #10 AWG
• Contact Rating : Oversized silver alloy contacts
• Features : Single Piece Plated Steel Mounting Strap
• Contact Configuration : One piece brass alloy contact arm
• Degree of Protection : 1500V Dielectric Withstand Voltage
• Special Features : Back & Side wire, locking support, one piece brass alloy contact arm
