Multi-Conductor Shielded, Plenum NEC Type CMP and/or CL3P #G111804

CABLE- 18-4 PLENUM SHIELDED

OMIG111804 G111804 OMIG111804
0.56 / EA
http://schema.org/OutOfStock
Mayer-DDS-Multi-Conductor Shielded, Plenum NEC Type CMP and/or CL3P #G111804-1
  • Cable Type: Security, Sound
  • Gauge: 18 AWG
  • Jacket Color: Natural
  • Jacket Material: Polyvinyl Chloride, PVC
  • Jacket Thickness: .015 in
  • Outside Diameter: .169 in
  • Temperature Rating: 75 °C
  • Type: Simple
This shielded, 16 AWG and 18 AWG, multi-conductor plenum thermostat cable has a PVC insulation and jacket.
QTY
  • Product Description
  • Specifications
This shielded, 16 AWG and 18 AWG, multi-conductor plenum thermostat cable has a PVC insulation and jacket.
  • Specifications
    • Cable Type : Sound and Security Cable
    • Conductor Material : Bare Copper
    • Conductors : 4
    • Gauge : 18
    • Insulation Material : PVC - Polyvinyl Chloride
    • Insulation Thickness : .008''
    • Item Class : PLG11
    • Jacket Color : Natural
    • Jacket Material : PVC - Polyvinyl Chloride
    • Jacket Thickness : .015''
    • Material Weight : 34
    • Material Weight KGKM : 50
    • Outside Diameter Inches : .169''
    • Product Type : Simple
    • Shield : Overall Flexfoil® polyester supported aluminum foil Stranded tinned copper drain wire
    • Shield Search : Yes
    • Temperature : 75C
    • Unit Of Measure : ft
    • Voltage Search : 300V
    • Weight : 1
