Nuts 3/8-16 Hx Nut St-zn (Jar 100)

3/8-16 FINISHED HEX NUT ZC C

MTLJN165D JN165D 639720500684
0.00 / EA
http://schema.org/OutOfStock
  • Country of Origin: MUL
  • Finish: Zinc
  • Height: 2.7 in
  • Length: 3 in, 76.2 mm
  • Material: Steel
  • Weight: 1.58 lb
  • Width: 3 in, 76.2 mm
3/8-16 Hex Nut USA Made Zinc
QTY
  • Product Description
  • Features
  • Specifications
3/8-16 Hex Nut USA Made Zinc
  • Features
    • Made to American Standard Dimensions
    • The most versatile and widely used nut design. Grade-2 nuts are for use with any low carbon bolt or screw that is not heat treated, with a specified minimum tensile strength of 74,000 psi or less
  • Additional Notes
    • Other sizes and quantities available by request
  • Specifications
    • Country of Origin : MUL
    • Length : 3 in
    • Width : 3 in
    • Height : 2.7 in
    • Weight : 1.58 lbs
    • Collection Folder : JN165D
    • NPD Date Electrical : 07/17/2014 00:00:00
    • MATERIAL : Steel
    • Thread Type : UNC
    • Division : Electrical H1
    • Field Application : Width is Wrench Size
    • COLOR : Silver
    • FINISH : Zinc
    • Sub-Division : Electrical-E H2
    • PRODUCT FAMILY : Electrical Supplies
    • Pack Type : Jar
    • Product Weight : 717 g
    • Product Width : 76.2 MM
    • Product Height : 68.58 MM
    • IGCC : 2862
    • Grade : 2
    • Thread Direction : Right Hand
    • Product Series : JN
    • NEURSPE : https://ideadigitalasset.com/DAMRoot/Original/10035/11237_ID-SPE-v1-ID-SPE-v1-Hex_Nut_Domestic_Gr_2_Gr_5_Gr_8_Gal_18-8_SS_316_SS.pdf
    • Type : Hexagonal Nut
    • Thread Per Inch : 16
    • Order Minimum Imperial : 100
    • ARRA Compliant : C
    • Order Minimum UOM Imperial : CT
    • Hardness : Rockwell B68-C32
    • Fastener Width : 0.320 - 0.337
    • Language Code : EN
    • Remarks : The catalog UPC differ from the tarnsaction daat spreadsheet UPC
    • Buy American Compliant : C
    • Fastener Height : 0.320 - 0.337
    • Product Length : 76.2 MM
    • Fastener Head Width : 0.551 - 0.562 in.
    • Thread Standard : ASME B18.2.2
