PSQ500QD, Multi-volt

BATTERY PACK NICAD 2.4V MVOLT

LITPSQ500QDMVOLTM12 PSQ500QD MVOLT M12 820476730016
175.61 / Each
http://schema.org/OutOfStock
Mayer-DDS-PSQ500QD, Multi-volt-1
  • Applications: Education, Government, Healthcare, Hospitality, House Of Worship, Manufacturing, Offices & Banks, Retail
  • Country of Origin: China
  • Environmental Conditions: Indoor
  • Height: 1.25 in
  • Length: 9.5 in
  • Product Type: Emergency Ballast
  • Standard: NFPA 101, UL
  • Warranty Length: 3 yr
  • Weight: 1.25 lb
  • Width: 2.25 in
The PSQ500 is designed to fit in the tightest of applications, including low-profile lensed troffers, downlighting and industrial lighting fixtures. They also feature an innovative Quick-Disconnect wiring harness that makes field maintenance and upgrades quick and easy. Factory or field installed inside or outside (field only) fluorescent fixture to operate lamp(s) at reduced light output, providing optimum glare-free illumination for a minimum of 90 minutes upon interruption of normal power. The nominal 500 lumen output is well-suited for fluorescent fixtures installed at standard ceiling heights.
QTY
  • Product Description
  • Features
  • Specifications
The PSQ500 is designed to fit in the tightest of applications, including low-profile lensed troffers, downlighting and industrial lighting fixtures. They also feature an innovative Quick-Disconnect wiring harness that makes field maintenance and upgrades quick and easy. Factory or field installed inside or outside (field only) fluorescent fixture to operate lamp(s) at reduced light output, providing optimum glare-free illumination for a minimum of 90 minutes upon interruption of normal power. The nominal 500 lumen output is well-suited for fluorescent fixtures installed at standard ceiling heights.
  • Features
    • The PSQ500 is designed to fit in the tightest of applications, including low-profile lensed troffers, downlighting and industrial lighting fixtures. They also feature an innovative Quick-Disconnect wiring harness that makes field maintenance and upgrades quick and easy. Factory or field installed inside or outside (field only) fluorescent fixture to operate lamp(s) at reduced light output, providing optimum glare-free illumination for a minimum of 90 minutes upon interruption of normal power. The nominal 500 lumen output is well-suited for fluorescent fixtures installed at standard ceiling heights.
    • DESIGN: Quick Disconnect harness design simplifies replacement of the unit after installation
    • INPUT POWER: 2.5W (max)
    • COMPATIBILTY: For use with most electronic T8 instant start, rapid start and slimline ballasts using 2-4 ft. T8 lamps or 4-pin long compact lamps
    • LISTINGS: UL listed. Meets UL 924, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards
    • VOLTAGE: Multi-voltage input capability (120-277V; 50/60 Hz)
    • EMERGENCY RUNTIME: 90 Minutes
    • INSTALLATION: Mounts concealed within fixture wireway for clean appearance and protection against vandalism
    • BATTERY: Sealed, maintenance-free, high-temperature nickel cadmium battery, Automatic battery recharge after 90-minute discharge, Fully charged after 24 hours.
    • WARRANTY: 3-Year Limited Warranty
  • Specifications
    • Product Type : Emergency Ballast
    • Application : Education,Government,Healthcare,Hospitality,House of Worship,Manufacturing,Offices & Banks,Retail
    • Standard : NFPA 101,UL
    • Voltage Rating : MVOLT
    • Environmental Conditions : Indoor
    • Maximum Operating Temperature : 50
    • Warranty : 3 Year Limited
    • Height : 1.25 in
    • Length : 9.5 in
    • Weight : 1.25 lbs
    • Width : 2.25 in
    • Country of Origin : China
