This step-down transformer is part of the Smart-UPS accessories. This is a 5kVA step-down transformer and can be used with 5kVA SRT On-Line rackmount UPS. It can be installed in a 19 inch rack with supplied rail kit. The UPS has an additional SmartSlot for connectivity and PowerChute Network Shutdown support for graceful unattended shutdown. It comes with NEMA L6-30P input and 12x NEMA 5-20R output. The UPS has a 2-year warranty. Its dimensions are 637mm (depth) x 89mm (height) x 432mm (width) and weighs 43.09kg. Ideal for servers, voice/data networks, medical labs, and light industrial applications. It conforms to CSA and UL 1778. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

• Features
• 5kVA step-down transformer Smart-UPS accessory
• Features 12 NEMA 5-20R outlets
• Rackmount form factor
• Suitable for high-density power distribution
• Extensive list of compatible products and accessories

• Physical Attributes
• Color : Black
• Complementary Attributes
• Curve Load Maximum : 100 %
• Maximum Total Current Draw Per Phase : 24 A
• Curve X Axis Maximum : 100 %
• Curve X Axis Minimum : 0 %
• Curve Y Axis Maximum : 100 %
• Curve Y Axis Minimum : 50 %
• Important Information Attributes
• Persona Type Ids : EUA, PB, SC, VR
• Persona Type Names : Consumer, Panel Builder, Electrician, IT Channel Partner
• Market Segmentation Id : RESIDENTIAL, COMMERCIAL, INDUSTRIAL
• Market Segmentation : Residential, Commercial, Industrial
• Provided Equipment : Mounting Hardware, Rack Mounting brackets, User Manual, Warranty card
• Carbon Footprint Of The Distribution Phase A4 : 3.5900056, 4 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4 : 3 kg CO2 eq., 3.1632608
• Carbon Footprint Of The Installation Phase A5 : 0, 0 kg CO2 eq.
• Carbon Footprint Of The Manufacturing Phase A1 To A3 : 176 kg CO2 eq., 176.45638
• Carbon Footprint Of The Use Phase B2 B3 B4 B6 : 4 358 kg CO2 eq., 4357.5674
• Local Data Status : Publishable
• Local Publishable Date : 2026-07-29
• Pre Comm Date : 2015-06-22
• Return Indicator : Y
• Device Type : UPS - Network and Server
• Serviceability : Yes
• Traceability : Yes
• Field Service Division : SPIBS
• Average Life Duration : 5 year(s)
• Service Catalog Item : Finished good
• Use Carbon Footprint : 4357.5674
• Weee Scope : In
• Weee Product Category : 4
• Scope Perimeter : At least in Europe
• Eoli Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1612029_EN
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• Rohs Eur In Scope : Yes
• Rohs Eur Status : Compliant By Exemption
• Rohs Eur Conformity Date : 2339
• Rohs Eur Full Compliance Status : Compliant By Exemption
• China Rohs In Scope : No
• With Recycled Cardboard : Yes
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Tier Id : 2
• Tier : 2
• Function Option Id : STANDARD
• Function Option : Standard
• Product Kit Identifier : N
• Curve Equation : efficiency
• Energy Efficiency Optimized : False
• Input Connection Type : NEMA L6-30P
• Load Capacity : 5000 VA
• Max Line Current : 24 A
• Mounting Location : front
• Mounting Mode : rack-mounted
• Mounting Position : horizontal
• Mounting Preference : no preference
• Number Of Cables : 1
• Number Of Power Socket Outlets : NEMA 5-20R12
• Number Of Rack Unit : 2U
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : transformer
• Range Of Product : Smart-UPS Accessories
• Returnability : Yes
• Software Version : v6.2.5-6
• Sustainable Packaging : No
• Total Lifecycle Carbon Footprint : 4 541 kg CO2 eq.
• Ups Size : S
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Database Version : 2024-01
• Data Source : extrapolated product
• Height Nominal : 89 mm
• Width Nominal : 432 mm
• Certificate Agency : CSA
• Nbr. Of Units In Pkg. : 1
• Customs Code : 8504320000
• Curve X Axis Title : load
• Curve X Axis Units : percentage
• Curve Y Axis Title : efficiency
• Curve Y Axis Units : percentage
• Carbon Footprint Kg Co2 Eq Total Life Cycle : 4540.8002
• Warranty In Months : 24
• Functional Unit Description : The functional unit is the transmission of electricity between electrical/electronic equipment and a power source for a distance of 2.5m for up to 10A of current at 230V AC
• Functional Unit Quantity : 1
• Functional Unit Unit : unit
• Reference Lifetime In Y : 10
• Recyclability Potential In % : 86
• Environment Attributes Main
• China Rohs Regulation : Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
• Ambient Air Temperature For Storage : -15-45 °C, -15-45 °C
• Take Back : Yes
• Recycled Metal Content At Cr Level : 0 %
• Carbon Footprint : 4540.8002
• Ambient Air Temperature For Operation : 0-40 °C
• Circularity Profile : ENVEOLI1612029_EN
• Environmental Disclosure : ENVPEP1612029_EN
• Eu Rohs Directive : Compliant By Exemption
• Operating Altitude : 0...10000 ft
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : No
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Relative Humidity : 0-95 % non-condensing
• Storage Altitude : 0-50000 ft
• Storage Relative Humidity : 0-95 % non-condensing
• Pep Code : ENVPEP1612029_EN
• Pep Verification Date : 2025-10-25
• Pcr Version : PEP-PCR-ed4-2021 09 06
• Psr Version : PSR-0002-ed3-EN-2023 06 06
• Type Of Verification For The Pep : Independent internal review
• General Attributes
• Provided Equipment : Mounting Hardware, Rack Mounting brackets, User Manual, Warranty card
• Product Or Component Type : transformer
• Range Of Product : Smart-UPS Accessories
• ETIM
• ETIM 8 : EC002850
• ETIM 9 : EC002850
• ETIM 10 : EC002850
• Output Attributes
• Output Voltage : 120 V
• Contractual Warranty Attributes
• Warranty Period : 2 years repair or replace
• Warranty : 2 years repair or replace
• Input Attributes
• Input Current Limits : 30 A
• Main Input Voltage : 208 V
• Specifications
• Country of Origin : United States
• Weight : 49900 g
• Depth : 637 mm
