No matter what the conditions require, operating at a variety of line voltages between 120V to 480V, whether located in high ambient temperature environments (requiring a 90° C rating) or not, our family of Philips Advance Centium ballasts are ideal for a wide variety of applications.
- Product Data
- Short product name : ELE BALLAST (2) F96T12/HO 120-277V
- Full product name : ELE BALLAST (2) F96T12/HO 120-277V
- Skus/Case : 10
- Bar code on pack : 781087085288
- Logistics code(s) : 913701212601
- eop_net_weight_pp : 0.613 kg
- Pieces per Sku : 1
- Product number : ICN2S110SC35I
- Bar code on case : 30781087085289
- Temperature Characteristics
- idw_core
- catalog : ICN2S110SC35I
- idwItemCtrl : 781087085288
- upc : 781087085288
- gtin : 00781087085288
- brandLabel : PHILIPS ADVANCE
- unspsc : 39101901
- igcc : 3700
- idwIndex : 10903176
- sequenceId : 346
- Product Dimensions
- Width B1 : 1.7 in
- Length A2 : 8.90 in
- Height C1 : 1.18 in
- Length A1 : 9.5 in
- Wiring Characteristics
- Allowed Wiring Config(Tandem) : Yes
- Allowed Wiring Config(Through) : Yes
- Lamp Connection : Series
- Wire Length by Color : See data sheet
- Max Dist. Ball to Lamp(Remote) : 20'
- Wire Striplength : 0.50/0.375 mm
- Color output terminals : No terminals
- Max Dist. Ball to Lamp(Tandem) : Red = 20'
- Color input terminals : No terminals
- Connector type : No connector
- Max Dist.Ball to Lamp(Through) : Red = 20'
- Allowed Wiring Config(Remote) : Yes
- Wire Type : Solid
- Wire Gauge : 18AWG
- General Characteristics
- Housing Dimensions : 9.5" x 1.7" x 1.18"
- Housing : SC
- Lamp Type : F96T12/HO
- Starting Method : Rapid Start
- Family Name : Centium
- Ballast Type : Electronic Fluorescent
- Line Frequency : 50/60 Hz
- Input Voltage : 120-277 V
- Number of Lamps : 1/2 piece
- Suitable for Outdoor use? : Yes
- Base Model : ICN2S110SC
- Housing Material : Metal
- Operating Characteristics
- Ignition time : 1 s
- Automatic restart : No
- Lamp Current Crest Factor : 1.7 -
- Max THD : 10 %
- Sound Rating : A
- Power Factor : 0.98
- Input Power Gear : 191-186 W
- Ballast factor : 0.9 -
- Ballast Efficacy Factor : 0.47 -
- Approval & Application Chars
- cUL certificate : No
- UL Recognized : No
- CSA certificate : Yes
- RoHS Compliant : Yes
- NEMA Premium : No
- FIDE Certificate : No
- SASO Certificate : No
- NOM certificate : No
- CEC Listing : Yes
- Circle E logo : Yes
- Energy Star : No
- EMC Immunity : FCC Non-Consumer
- UL Listed : Yes
- CEE Rated : No
- CSA E : Yes
- DOE : Yes
- Approbation Marks : UL, CSA, DOE, CSA-E, RoHS
- System Chars On Driver Level
