Audible Visual Flashing LED Light, UL and cUL, 120VAC, Red

LED AUDIBLE/VIS RED 120V

FEDAV1LED120R AV1-LED-120R 782979227601
375.77 / BOX
http://schema.org/OutOfStock
Mayer-DDS-Audible Visual Flashing LED Light, UL and cUL, 120VAC, Red-1
  • Certifications: CUL, UL
  • Country of Origin: USA
  • Depth: 16.459 cm, 6.48 in
  • Diameter: 14.630 cm, 5.76 in
  • Height: 16.459 cm, 6.48 in
  • Lens Color: Red
  • Mounting Type: 1/2-Inch Pipe, 4" Square Electrical Box, Surface
  • Weight: 1.25 lb
The model AV1-LED warning light is a combination audible/visual signal. The warning light also features a 100% polycarbonate housing that is rated for Type 3R rain-tight applications.All AV1-LED alert light units feature a twist-and-lock lens design to allow for tool-free access to the LED. The Fresnel lens provides superior visibility in all directions.The integrated buzzer provides 85 dBa output @ 10 feet (95 dBa @ 1M). The unit can operate in two ways: flashing/buzzer combination or flashing only. The LED flash pattern can be field adjusted to 60 FPM or 75 FPM, via a jumper on the PC board.Each unit is factory-assembled with two color-coded leads. If desired, the user can remove the leads and connect directly to the terminal block located at the base of the unit.
QTY
  • Product Description
  • Features
  • Specifications
The model AV1-LED warning light is a combination audible/visual signal. The warning light also features a 100% polycarbonate housing that is rated for Type 3R rain-tight applications.All AV1-LED alert light units feature a twist-and-lock lens design to allow for tool-free access to the LED. The Fresnel lens provides superior visibility in all directions.The integrated buzzer provides 85 dBa output @ 10 feet (95 dBa @ 1M). The unit can operate in two ways: flashing/buzzer combination or flashing only. The LED flash pattern can be field adjusted to 60 FPM or 75 FPM, via a jumper on the PC board.Each unit is factory-assembled with two color-coded leads. If desired, the user can remove the leads and connect directly to the terminal block located at the base of the unit.
  • Features
    • Available in 24VDC and 120VAC
    • Five lamp/lens colors: Amber, Blue, Clear, Green and Red
    • 50,000 hour LED
    • Surface, integrated 1/2-inch NPT pipe, and 4-inch electrical box mount
    • Twist-off lens for easy access
    • Internal buzzer produces 85 dBa at 10' (95 dBa @ 1m)
    • Flexible operation allows the unit to independently flash without buzzer if desired
    • PLC compatible
    • Type 3R enclosure
    • UL and cUL Listed
  • Specifications
    • Country of Origin : United States
    • Weight : 1.25 lbs
    • Body Color : Black
    • Candela Power Peak : 125
    • Certification Listing : UL, cUL
    • dBa 1 Meter : 95
    • dBa 10 Ft : 85
    • Diameter (in) : 5.76
    • Diameter (mm) : 146.304
    • Flashes Per Minute : 60-75
    • Availability : In Stock - Ships in 2 Bus Days
    • Lens Color : Red
    • Mount Type : 1/2-Inch Pipe, 4" Square Electrical Box, Surface
    • Operating Current Amps : 0.03
    • Operating Temp. : -31˚ to +150˚F (-35˚ to +66˚C)
    • Visual Signals Lens Color : Red
    • Visual Signals Operating Voltage : 120VAC
    • Depth : 6.48 in, 16.4592 cm
    • Height : 6.48 in, 16.4592 cm
    • Diameter : 5.76 in, 14.6304 cm
