Schneider Electric at Mayer

distributed analog input Modicon Momentum - 4 Input

RTD TC MV INPUT 4 CH.DIFF

SQD170AAI52040 170AAI52040 3389110886498
1868.58 / EA
http://schema.org/OutOfStock
Mayer-DDS-distributed analog input Modicon Momentum - 4 Input-1
  • Depth: 47.5 mm
  • Warranty Length: 18 mth
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This analog input base offers 4 inputs with a full 16bit signed resolution. It offers differential analog input ranges from ±100mV, ±25mV. There is an isolation between channels and bus, channels and ground at 500V AC. It is furnished with 2 removable terminal blocks for electrical connection. It features 4 LEDs for channel status signaling. Its dimensions are 141.5mm (width) x 47.5mm (depth) x 125mm (height). It weighs 0.215kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
QTY
  • Product Description
  • Features
  • Specifications
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This analog input base offers 4 inputs with a full 16bit signed resolution. It offers differential analog input ranges from ±100mV, ±25mV. There is an isolation between channels and bus, channels and ground at 500V AC. It is furnished with 2 removable terminal blocks for electrical connection. It features 4 LEDs for channel status signaling. Its dimensions are 141.5mm (width) x 47.5mm (depth) x 125mm (height). It weighs 0.215kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Assets
    • Cad : https://download.schneider-electric.com/files?p_Doc_Ref=AAI5204W&p_File_name=AAI5204W.dwg, https://download.schneider-electric.com/files?p_Doc_Ref=AAI5204W&p_File_name=AAI5204W.dxf, https://download.schneider-electric.com/files?p_Doc_Ref=ADI3400R&p_File_name=ADI3400R.dwg, https://download.schneider-electric.com/files?p_Doc_Ref=ADI3400R&p_File_name=ADI3400R.dxf, https://download.schneider-electric.com/files?p_Doc_Ref=wiring for the 170aai14000 and 170aai52040 io base
  • Conformance Attributes
    • Product Certifications : FM Class 1 Division 2, CSA, UL
  • Important Information Attributes
    • Persona Type Ids : EU, OM8, SI
    • Persona Type Names : End User, OEM - Control Panelbuilder, System Integrator
    • Medium Desc : distributed analog input Modicon Momentum - 4 Input
    • Local Data Status : Publishable
    • Local Publishable Date : 2026-01-12
    • Global Commercial Status : Commercialised
    • Return Indicator : Y
    • Stocking Flag : N
    • Device Type : PLC System - PLC Component
    • Serviceability : No
    • Traceability : Yes
    • Field Service Division : IDIBS
    • Average Life Duration : 15 year(s)
    • Legacy Weee Scope : Out
    • Scope Perimeter : At least in Europe
    • Eoli Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI1403005EN
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • Rohs Eur In Scope : No
    • Rohs Eur Status : Compliant By Exemption
    • Rohs Eur Full Compliance Status : Compliant By Exemption
    • China Rohs In Scope : Yes
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Function Option Id : ADVANCED
    • Function Option : Advanced
    • Market Segmentation Id : INDUSTRIAL
    • Market Segmentation : Industrial
    • Product Kit Identifier : N
    • Data Format : full 16 bits signed
    • Marking : CE
    • Power Consumption In W : 5.5 W
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : analogue input base
    • Protective Treatment : TC
    • Range Of Product : Modicon Momentum automation platform
    • Returnability : Yes
    • Reverse Polarity Protection : internal
    • Sustainable Packaging : No
    • Update Time : 500 ms
    • Dc Supply Voltage : 24-24 V
    • Pep Code : ENVPEP1403005EN
    • Height Nominal : 125 mm
    • Width Nominal : 141.5 mm
  • Environment Attributes Main
    • Take Back : Nej
    • Recycled Metal Content At Cr Level : 0 %
    • China Rohs Regulation : X
    • Mercury Free : Yes
    • Circularity Profile : ENVEOLI1403005EN
    • Environmental Disclosure : ENVPEP1403005EN
    • Eu Rohs Directive : Compliant By Exemption
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP1403005EN
  • General Attributes
    • Product Or Component Type : analogue input base
    • Range Of Product : Modicon Momentum automation platform
  • ETIM
    • ETIM 8 : EC001596
    • ETIM 9 : EC001596
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Input Attributes
    • Analogue Input Number : 4
  • Specifications
    • Depth : 47.5 mm
