This Harmony XB5, monolithic analog timer can be set for timing intervals between 0.5 to 10 seconds and is supplied with a 100V to 240V AC/DC input. This analog timer provides visual timing of your processes. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. It provides highly visible timing of machine processes, ensuring accuracy and consistency of operation.

• Prop 65
• WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Specifications
• Country of Origin : France
• Width : 29 mm
• Height : 62 mm
• Weight : 0.027 kg
• Range Of Product : Harmony XB5
• Product Or Component Type : timer
• Sale Per Indivisible Quantity : 1
• Complementary
• Product Certifications : CE || UL Listed
• [Us] Rated Supply Voltage : 110...230 V AC/DC
• Setting Accuracy Of Time Delay : +/- 10 % of full scale 25 °C IEC 61812-1
• Ambient Air Temperature For Operation : -20-60 °C
• Height : 62 mm
• Resistance To Electromagnetic Fields : 10 V/m 80 MHz...1 GHz level 3 IEC 61000-4-3 || 3 V/m 1.4...2 GHz level 2 IEC 61000-4-3 || 1 V/m 2...2.7 GHz level 1 IEC 61000-4-3
• Diameter : 29 mm
• Maximum Voltage Drop : 5 V
• Standards : IEC 61812-1 || UL 508
• Disturbance Radiated/Conducted : class B EN 50022
• Repeat Accuracy : +/- 0.5 %
• Mounting Diameter : 22 mm
• Power Consumption In W : 1 W
• Shape Of Signaling Unit Head : round
• Dielectric Strength : 1500 V IEC 61812-1
• Vibration Resistance : 0.15 mm (f= 10-60 Hz) conforming to IEC 60068-2-6 || 2 gn (f= 60-150 Hz) conforming to IEC 60068-2-6
• Shock Resistance : +/- 15 gn 11 ms 6 shocks on each axis)IEC 60068-2-27
• Reset Time : 30 ms after time delay on de-energisation || 60 ms during time delay on de-energisation
• Net Weight : 0.027 kg
• [Uimp] Rated Impulse Withstand Voltage : 4 kV IEC 60947-1 || 4 kV IEC 60664-1
• Fixing Collar Material : plastic
• Voltage Drift : +/- 0.2 %/V
• Device Presentation : monolithic product
• Thickness : 1-6 mm
• Electromagnetic Compatibility : electrostatic discharge 6 kV level 3 conforming to IEC 61000-4-2 || electromagnetic emission class B conforming to IEC 55011
• Temperature Drift : +/- 0.05 %/°C
• Time Delay Range : 0.5...10 s
• Local Signalling : LED green, steady timing in progress || LED, off no timing in progress and output relay energised
• Pollution Degree : 3 IEC 60664-1
• [Ui] Rated Insulation Voltage : 250 V IEC 60947-1 || 250 V IEC 60664-1
• Ambient Air Temperature For Storage : -20-80 °C
• Surge Withstand : 2 kV, level 3 IEC 61000-4-5
• Power Consumption In Va : 1.5 VA
• Overvoltage Category : class 3 conforming to IEC 60536 || class 3 conforming to IEC 60664-1
• Bezel Material : plastic
• Tightening Torque : 0.5 N.m
• Output Short-Circuit Protection : no
• Connections - Terminals : screw terminals 1 x 4 mm² IEC 60947-1 || screw terminals 1 x 2.5 mm² IEC 60947-1
• Minimum Switching Current : 10 mA
• Supply Voltage Limits : 93.5-253 V AC/DC
• Temporary Permissible Current : 10 A 0.01 s
• Ip Degree Of Protection : IP65 front: conforming to IEC 60529 || IP20 back: conforming to IEC 60529
• Maximum Residual Current : 5 mA
• Protection Type : overvoltage protection
• Width : 29 mm
• Output Type : thyristor
• Time Delay Type : A
• Depth : 29 mm
• Immunity To Radioelectric Fields : 10 V level 3 IEC 61000-4-6
• Resistance To Fast Transients : 2 kV level 3 IEC 61000-4-4
• Environmental data
• Rohs Exemption Information : Yes
• Packaging Made With Recycled Cardboard : No
• Mercury Free : Yes
• Packaging Without Single Use Plastic : No
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Minimum Percentage Of Recycled Plastic Content : 0
• Take-Back : No
• Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
