SQUARE D

Head for double headed push button, Harmony XB5, plastic, 22mm, 1 green flush marked I + 1 red flush marked O

HARMONY XB5, DOUBLE-HEADED PUS

SQDZB5AA7341 ZB5AA7341 3389119043298
38.39 / EA
http://schema.org/OutOfStock
Mayer-DDS-Head for double headed push button, Harmony XB5, plastic, 22mm, 1 green flush marked I + 1 red flush marked O-1
  • Bezel Material: Plastic
  • Certifications: BV, CSA, DNV, GL, LROS (Lloyds Register Of Shipping), UL Listed
  • IsSustainable: No
  • Net Weight: 0.023 kg
  • Standard: CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508
  • Storage Temperature: -40-70 °C
  • Warranty Length: 18 mth
This double head provides a versatile interface for controlling your machines, it has 1 red and 1 green buttons. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear colors. It is also distinguishable by touch due to flush elements, minimizing errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
QTY
  • Product Description
  • Specifications
This double head provides a versatile interface for controlling your machines, it has 1 red and 1 green buttons. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear colors. It is also distinguishable by touch due to flush elements, minimizing errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
  • Environment
    • Ik Degree Of Protection : IK03 IEC 50102
    • Shock Resistance : 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    • Protective Treatment : TH
    • Standards : JIS C8201-5-1 || CSA C22.2 No 14 || IEC 60947-1 || IEC 60947-5-1 || UL 508 || IEC 60947-5-4 || JIS C8201-1
    • Ambient Air Temperature For Operation : -25-70 °C
    • Nema Degree Of Protection : NEMA 13 || NEMA 4X
    • Resistance To High Pressure Washer : 7000000 Pa 55 °C 0.1 m
    • Product Certifications : CSA || LROS (Lloyds register of shipping) || UL Listed || DNV || BV || GL
    • Electrical Shock Protection Class : class II IEC 60536
    • Vibration Resistance : 5 gn 2-500 Hz)IEC 60068-2-6
    • Ambient Air Temperature For Storage : -40-70 °C
    • Ip Degree Of Protection : IP66 IEC 60529 || IP69K IEC 60529
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Circularity Profile : ENVEOLI1710010EN
    • Reach Free Of Svhc : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • China Rohs Regulation : X
    • Rohs Exemption Information : Yes
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Environmental Disclosure : ENVPEP1710010EN
    • Sustainable Offer Status : Green Premium product
  • Complementary
    • Cad Overall Depth : 30 mm
    • Station Name : XALD 1 cut-out
    • Mechanical Durability : 1000000 cycles
    • Cad Overall Width : 30 mm
    • Cad Overall Height : 50 mm
    • Device Presentation : basic element
    • Colour Of Marking : black marking when white caps || white marking when green, red or black caps
    • Operator Profile : green flush, I white) || red flush, O white)
    • Net Weight : 0.023 kg
    • Electrical Composition Code : C3 6 single front mounting || C4 6 single and double front mounting || C14 2 single front mounting || SF2 2 single front mounting || SR2 2 single rear mounting
  • Specifications
    • Operator Profile : 2 flush push-buttons
    • Operators Description : green ''I'' - red ''O''
    • Product Or Component Type : head for double-headed push-button
    • Sale Per Indivisible Quantity : 1
    • Range Of Product : Harmony XB5
    • Shape Of Signaling Unit Head : rectangular
    • Type Of Operator : spring return
    • Head Type : standard
    • Device Short Name : ZB5
    • Mounting Diameter : 22 mm
    • Bezel Material : dark grey plastic
