SQUARE D

Head for double headed push button, Harmony XB4, metal, 22mm, 1 green flush unmarked+1 red projecting unmarked

HARMONY XB4, DOUBLE-HEADED PUS

SQDZB4BL7340 ZB4BL7340 3389119043854
32.55 / EA
http://schema.org/OutOfStock
Mayer-DDS-Head for double headed push button, Harmony XB4, metal, 22mm, 1 green flush unmarked+1 red projecting unmarked-1
  • Bezel Material: Chromium Plated Metal
  • Certifications: BV, CSA, DNV, GL, LROS (Lloyds Register Of Shipping), UL Listed
  • IsSustainable: No
  • Net Weight: 0.056 kg
  • Standard: CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, IEC 60947-5-5, JIS C8201-1, JIS C8201-5-1, UL 508
  • Storage Temperature: -40-70 °C
  • Warranty Length: 18 mth
This Harmony XB4, double head has 1 green and 1 red button, operates with a spring return / impulse mechanism. This double head provides a versatile interface for controlling your machines. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear colors and by touch due to flush and projecting elements, minimizing errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
QTY
  • Product Description
  • Specifications
This Harmony XB4, double head has 1 green and 1 red button, operates with a spring return / impulse mechanism. This double head provides a versatile interface for controlling your machines. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to clear colors and by touch due to flush and projecting elements, minimizing errors in machine control. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It has a metal bezel, this makes it Ideal for applications requiring high impact and vibration resistance. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
  • Environment
    • Shock Resistance : 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    • Vibration Resistance : 5 gn 2-500 Hz)IEC 60068-2-6
    • Product Certifications : UL Listed || GL || DNV || CSA || BV || LROS (Lloyds register of shipping)
    • Ip Degree Of Protection : IP69 IEC 60529 || IP66 IEC 60529 || IP69K
    • Ambient Air Temperature For Storage : -40-70 °C
    • Nema Degree Of Protection : NEMA 13 || NEMA 4X
    • Ambient Air Temperature For Operation : -40-70 °C
    • Electrical Shock Protection Class : class I IEC 60536
    • Standards : UL 508 || JIS C8201-5-1 || IEC 60947-1 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-5-4 || IEC 60947-5-5 || JIS C8201-1
    • Ik Degree Of Protection : IK03 IEC 50102
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Environmental Disclosure : ENVPEP1808008EN
    • Mercury Free : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • Rohs Exemption Information : Yes
    • Sustainable Offer Status : Green Premium product
    • Circularity Profile : ENVEOLI1808008EN
    • Toxic Heavy Metal Free : Yes
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • China Rohs Regulation : X
    • Reach Free Of Svhc : Yes
  • Complementary
    • Net Weight : 0.056 kg
    • Colour Of Marking : white marking when green, red or black caps || black marking when white caps
    • Resistance To High Pressure Washer : 7000000 Pa 55 °C 0.1 m
    • Device Presentation : basic element
    • Operator Profile : green flush, unmarked || red projecting, unmarked
    • Electrical Composition Code : C3 6 single front mounting || C4 6 single and double front mounting || C14 2 single front mounting
    • Mechanical Durability : 1000000 cycles
  • Specifications
    • Type Of Operator : spring return
    • Shape Of Signaling Unit Head : rectangular
    • Operator Profile : 1 flush - 1 projecting push-buttons
    • Bezel Material : chromium plated metal
    • Operators Description : green unmarked - red unmarked
    • Sale Per Indivisible Quantity : 1
    • Product Or Component Type : head for double-headed push-button
    • Range Of Product : Harmony XB4
    • Head Type : standard
    • Device Short Name : ZB4
    • Mounting Diameter : 22 mm
