This braking resistor allows your drive to operate while braking to a standstill or during slowdown braking. It dissipates the braking energy, and enables maximum transient braking torque. It has an Ohmic value of 15Ohms at 20°C and its protection index is IP20. It is compatible with Altivar 312, Altivar 61, Altivar 71, Lexium 32 / 32i and lexium 52.

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Environment
• Ambient Air Temperature For Operation : 0-50 °C
• Ip Degree Of Protection : IP20
• Ambient Air Temperature For Storage : -25-70 °C
• Contractual warranty
• Warranty : 18 months
• Environmental data
• Rohs Exemption Information : Yes
• Packaging Made With Recycled Cardboard : No
• Mercury Free : Yes
• Packaging Without Single Use Plastic : No
• Toxic Heavy Metal Free : Yes
• Reach Regulation : Free of Substances of Very High Concern above the threshold
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Reach Free Of Svhc : Yes
• Minimum Percentage Of Recycled Plastic Content : 0
• Take-Back : No
• Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
• Complementary
• Continuous Power : 1000 W
• Height : 484 mm
• Protection Type : thermal protection via drive or temperature control switch 120 °C
• Net Weight : 11 kg
• Electrical Connection : M6 bar wire drive || terminal <= 2.5 mm² / AWG 14 temperature control switch
• Width : 240 mm
• Depth : 301 mm
• Average Power Available : 1 kW 50 °C || 1.154 kW 40 °C
• Contact Resistance : 60 µOhm
• Specifications
• Country of Origin : Germany
• Width : 240 mm
• Height : 484 mm
• Weight : 11 kg
• Ohmic Value : 15 Ohm
• Range Of Product : Altivar
• Product Compatibility : ATV312HU55M3 || ATV312HU75M3 || ATV61HD18N4 || ATV61HD22N4 || ATV61HD30N4 || ATV61HD30Y || ATV61HD37Y || ATV61HD45Y || ATV61HU55M3 || ATV61HU75M3 || ATV61WD22N4 || ATV61WD22N4C || ATV61WD30N4 || ATV61WD30N4C || ATV61WD37N4 || ATV61WD37N4C || ATV71HD18N4 || ATV71HD22N4 || ATV71HD22Y || ATV71HD30N4 || ATV71HD30Y || ATV71HD37Y || ATV71HU55M3 || ATV71HU75M3 || ATV71WD18N4 || ATV71WD22N4 || ATV71WD30N4 || LXM32MC10N4 || LXM32MD85N4
• Accessory / Separate Part Category : protection accessories
• Product Or Component Type : braking resistor
• Range Compatibility : Altivar 312 Solar || Lexium 32 || Altivar 61 || Lexium 32i || Altivar 312 || Lexium 52
• [Ue] Rated Operational Voltage : 24 V DC 0.1 A || 250 V AC 1 A
