Power Sentry batteries fit in the tightest of applications, including low-profile lensed troffers, downlighting and industrial lighting fixtures. They also feature an innovative Quick-Disconnect wiring harness that makes field maintenance and upgrades quick and easy. Specification-grade emergency ballast operates one or two lamps (4' or shorter) or one 8' lamp. Factory or field installed within fluorescent fixture ballast channel. Upon interruption of normal power battery pack automatically strikes and operates lamps at reduced light output, providing glare-free illumination for 90 minutes. The 1400 nominal lumens output is ideal for fixtures installed in higher ceiling heights or critical egress applications.

• Features
• Power Sentry batteries fit in the tightest of applications, including low-profile lensed troffers, downlighting and industrial lighting fixtures. They also feature an innovative Quick-Disconnect wiring harness that makes field maintenance and upgrades quick and easy. Specification-grade emergency ballast operates one or two lamps (4' or shorter) or one 8' lamp. Factory or field installed within fluorescent fixture ballast channel. Upon interruption of normal power battery pack automatically strikes and operates lamps at reduced light output, providing glare-free illumination for 90 minutes. The 1400 nominal lumens output is ideal for fixtures installed in higher ceiling heights or critical egress applications.
• DESIGN: Quick Disconnect harness for easy replacement in the field.
• INPUT POWER: 3.3W (max)
• COMPATIBILITY: For use with linear T5/T8 and 4-pin compact fluorescent lamps using instant start, rapid start, and slimline ballasts.
• RATINGS: UL listed. 0° - 50°C (32° - 122°F). Meets UL 924, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards
• VOLTAGE: Multi-voltage input capability (120V-277V; 50-60 Hz)
• EMERGENCY RUNTIME: 90 Minutes
• INSTALLATION: Clean installation within the fixture's channel compartment or troffer space.
• BATTERY: Sealed, maintenance-free, high-temperature nickel-cadmium battery. Automatic battery recharge after 90-minute discharge. Fully charged after 24 hours.
• WARRANTY: 5-Year Limited Warranty

• Specifications
• Product Type : Emergency Ballast
• Application : Education,Government,Healthcare,Hospitality,House of Worship,Manufacturing,Offices & Banks,Retail
• Standard : NFPA 101,UL
• Voltage Rating : MVOLT
• Color : Black
• Lamp Type : Not Applicable
• Shape : Not Applicable
• Environmental Conditions : Indoor
• Maximum Operating Temperature : 50
• Warranty : 5 Year Limited
• Height : 1.25 in
• Length : 13.375 in
• Weight : 2.1 lbs
• Width : 2.25 in
• Country of Origin : China
