3M™ Performance Plus™ Wire Connector T/R+POUCH, 100 per Pouch, 1000/Case

3M T/R+BOX SUPER TAN CONNECTOR

MMMTR+POUCH T/R+POUCH 51128544549
0.22 / EA
http://schema.org/OutOfStock
Mayer-DDS-3M™ Performance Plus™ Wire Connector T/R+POUCH, 100 per Pouch, 1000/Case-1
  • Country of Origin: USA
  • Material: Plastic
  • Max. Operating Temperature: 105.0 °C, 221.0 °F
  • Product Type: Connector
3M™ Performance Plus™ Wire Connectors are designed with a uniquely flexible spring that has generous room for expansion and a strong bite for a secure connection. Because of their increased wire range, just three Performance Plus wire connectors handle the work of eight standard connectors. And the flexible skirt helps prevent copper exposure for enhanced safety.
QTY
  • Product Description
  • Features
  • Specifications
3M™ Performance Plus™ Wire Connectors are designed with a uniquely flexible spring that has generous room for expansion and a strong bite for a secure connection. Because of their increased wire range, just three Performance Plus wire connectors handle the work of eight standard connectors. And the flexible skirt helps prevent copper exposure for enhanced safety.
  • Features
    • STRONG BITING SPRING: for a secure, reliable and long-lasting connection in all your pigtail applications
    • UNIQUELY FLEXIBLE SPRING that has generous room for expansion into greater wire range and reuse
    • DUAL COLOR CODED TAN/RED: one connector does the job of two traditional connectors in the majority of applications
    • UL LISTED for 600 volts on with copper wire only and 1000 volts maximum in signs and lighting fixtures (luminaries)
    • WIRE RANGE: 22-8 AWG for solid and/or stranded copper conductors
    • FLEXIBLE SKIRT helps prevent copper exposure for enhanced safety
  • Specifications
    • Country of Origin : United States
    • RDS URL (Regulatory Data Sheet) : https://multimedia.3m.com/mws/mediawebserver?mwsId=SSSSSu9n_zu8l00xNx_9M8me4v70k17zHvu9lxtD7xt1evSSSSSS-
    • AIS URL (Article Information Sheet) : https://multimedia.3m.com/mws/mediawebserver?mwsId=SSSSSu9n_zu8l00xNx_9M8me4v70k17zHvu9lxtD7xtBevSSSSSS-
    • ETIM Class 7.0 : EC000306
    • ETIM Class 8.0 : EC000306
    • Maximum Conductor Size (Imperial) : 8 AWG
    • Maximum Conductor Size (Metric) : 10
    • Maximum Operating Temperature (Celsius) : 105.0 Degree
    • Maximum Operating Temperature (Fahrenheit) : 221.0 Degree
    • Minimum Conductor Size (Imperial) : 22 AWG
    • Minimum Conductor Size (Metric) : .34 mm²
    • Product Color : Red
    • Voltage Rating : 600 Volt
    • Connection Type : Wire
    • Connector Style : Twist On
    • Flame Retardant : Yes
    • Manufacturing Origin : USA
    • Material : Plastic
    • Maximum Insulation Outer Diameter (Metric) : 3.7 mm
    • Maximum Insulation Outside Diameter : 0.145 in
    • Maximum Recommended Voltage Rating : 600.0 V
    • Packaging : Pouch
    • Product Type : Connector
    • RoHS EU Comments : RoHS 2011/65/EU compliant without exemption
    • Specifications Met : CSA, UL Listed
    • Wire Connector Type : Twist-on Wire Connectors
