Barrel Diameter:
0.25 in
-
Barrel Length:
0.25 in, 6.35 mm
-
Barrel Type:
Butted
-
Conductor Size:
10 AWG
-
Connection Type:
Butt
-
Country of Origin:
USA
-
Insulation Material:
Vinyl
-
Material:
Plastic
-
Max. Operating Temperature:
105 °C, 221 °F
-
Overall Length:
1.02 in, 25.908 mm
-
Package Height:
5.500 in
-
Package Length:
0.500 in
-
Package Weight:
0.134 lb
-
Terminal Style:
Standard
-
Terminal Type:
Butt Connectors
3M™ Highland™ Color-Coded Butt Splice Connector ensures an ideal fit while offering reliable and safe performance. The connector has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). The electrolytic copper terminal offers good conductivity and a tin-plated finish resists corrosion.
