GENERAL CABLE

24/1P STRANDED TC DUAL SHIELDED CM

BLD9841EQUAL 24/1PR SHLD LO-CA

GCCC4841A.41.10 C4841A.41.10 079407050420
1.00 / EA
http://schema.org/OutOfStock
Mayer-DDS-24/1P STRANDED TC DUAL SHIELDED CM-1
  • Country of Origin: USA
  • Flame Retardant: No
  • Jacket Color: Gray
  • Jacket Material: PVC
  • Lead Free: Yes
  • Number of Strands: 7/32
  • UV Resistant: No
  • Voltage: 300 V
Conductor: 24 AWG fully annealed stranded tinned copper per ASTM B33 • Twisted pairs Insulation: Premium-grade, coIor-coded polyethylene Shield: 100% Flexfoil® aluminum/polyester with 25% overlap, minimum, foil facing out • Stranded tinned copper drain wire • 90% tinned copper braid Jacket: PVC, gray • Temperature range: -20˚C to +80˚C Applications: Computers • Industrial equipment • Data transmission • Control circuits • Low capacitance requirements • Suitable for EIA RS-485 applications • Suggested voltage rating: 30 volts Compliances: NEC Article 800 Type CM/CMH (UL: 75°C, 300 V) • UL Style 2919 (UL: 80˚C, 30 V) • RoHS Compliant Directive 2015/863/EU (RoHS-3) • Passes CSA CMH Flame Test
QTY
  • Product Description
  • Features
  • Specifications
Conductor: 24 AWG fully annealed stranded tinned copper per ASTM B33 • Twisted pairs Insulation: Premium-grade, coIor-coded polyethylene Shield: 100% Flexfoil® aluminum/polyester with 25% overlap, minimum, foil facing out • Stranded tinned copper drain wire • 90% tinned copper braid Jacket: PVC, gray • Temperature range: -20˚C to +80˚C Applications: Computers • Industrial equipment • Data transmission • Control circuits • Low capacitance requirements • Suitable for EIA RS-485 applications • Suggested voltage rating: 30 volts Compliances: NEC Article 800 Type CM/CMH (UL: 75°C, 300 V) • UL Style 2919 (UL: 80˚C, 30 V) • RoHS Compliant Directive 2015/863/EU (RoHS-3) • Passes CSA CMH Flame Test
  • Applications
    • Computers
    • Industrial equipment
    • Data transmission
    • Control circuits
    • Low capacitance requirements
    • Suitable for EIA RS-485 applications
    • Suggested voltage rating: 30 volts
    • Building Installations
    • Industrial Installations
    • Datacenters
  • Jacket
    • PVC, gray
    • Temperature range: -20˚C to +80˚C
  • Compliances
    • NEC Article 800 Type CM/CMH (UL: 75°C, 300 V)
    • UL Style 2919 (UL: 80˚C, 30 V)
    • RoHS Compliant Directive 2015/863/EU (RoHS-3)
    • Passes CSA CMH Flame Test
  • Conductor
    • 24 AWG fully annealed stranded tinned copper per ASTM B33
    • Twisted pairs
  • Insulation
    • Premium-grade, coIor-coded polyethylene
  • Shield
    • 100% Flexfoil® aluminum/polyester with 25% overlap, minimum, foil facing out
    • Stranded tinned copper drain wire
    • 90% tinned copper braid
  • Specifications
    • Country of Origin : United States
    • AWG Size : 24
    • Conductor Category : Class 2 = stranded
    • Number of Conductors : 2
    • Strand Count : 7/32
    • Shape of Conductor : Round
    • Jacket Color : Gray
    • Jacket Marking : CAROL (R) 24 AWG -- C4841A -- 75C E105765-H CM (UL) C(UL) CMH OR 80C AWM STYLE 2919 30V LOW VOLTAGE COMPUTER CABLE -- ROHS CE -- MADE IN USA (date code - MM/YY) (sequential footage)
    • Outer Diameter : 0.235 in
    • Thickness Outer Jacket : 0.032 in
    • Insulation Thickness : 0.024 in
    • Armoring Type : None
    • Shield Construction : Metalized foil and braid
    • Shield Material : Aluminium
    • Jacket Material : Polyvinyl chloride (PVC)
    • Voltage : 300 V
    • Silicone Free : No
    • Lead Free : Yes
    • Resistant To Chemicals : No
    • Resistant To UV : No
    • Resistant To Moisture : No
    • Resistant To Oil : No
    • Flame Retardant : No
    • Halogen Free : No
    • Underground Installation : No
    • With Rodent Protection : No
    • Outdoor Installation : No
    • NVP Vaule : 66
