SQUARE D

Meter socket, ringless, 1 phase, 3 wire, 200A, 4 jaws, 600VAC max, Series A, no bypass, no jaw release

MTR SKT 200A 1PH HCP

SQD1004710E 1004710E 785901558538
254.54 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Meter socket, ringless, 1 phase, 3 wire, 200A, 4 jaws, 600VAC max, Series A, no bypass, no jaw release-2
  • Certifications: UL
  • Enclosure Material: Steel
  • Mounting Type: Surface
  • Number of Phases: 1
  • Warranty Length: 18 mth
QTY
  • Specifications
  • Environment
    • Product Certifications : UL Listed
    • Nema Degree Of Protection : NEMA 3R
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Eu Rohs Directive : Under investigation
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Nickel (Metallic), which is known to the State of California to cause cancer, and Toluene, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Complementary
    • Service Feed Location : UG || OH
    • Meter Socket Rated Current : 200 A
    • Device Mounting : surface
    • [Ue] Rated Operational Voltage : 600 V AC
    • Bypass Type : no bypass
    • Enclosure Material : steel
    • Awg Gauge : AWG 8...250 kcmil aluminium/copper)line side
    • Wiring Configuration : 3-wire
    • Electrical Connection : lugs 0.5" hex
    • Number Of Jaws : 4 without jaw release
    • Phase : 1 phase
  • Specifications
    • Hub Type : A ACP closing plate
    • Meter Socket Type : ringless
    • Product Or Component Type : Meter Socket
