Surgelogic™ EMA and EBA series SPDs, HL2IMA12C, offer a full range of externally mounted surge suppression solutions. These units are designed to provide surge suppression from service entrance panels to point-of-use equipment. US and Canadian UL® Listed to the UL 1449 standard. Complies with requirements of NEC® Article 285 and CSA 22.2 No. 8- M1986 as appropriate. Complies with UL 96A 12th Edition Master Label requirements for Lightning Protection Systems. They can be installed in accessory compartments behind the circuit breaker accessory cover. This accessory Certified to UL, IEC, CSA, CE, CCC, Standards.

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Environment
• Standards : UL 1449:ed. 3 || UL 1283:ed. 5 || CSA C22.2 No 8:1986 || UL 96A:ed. 12 || UL 489:ed. 11 || CSA C22.2 No 5-09
• Nema Degree Of Protection : NEMA 2
• Contractual warranty
• Warranty : 18 months
• Environmental data
• Packaging Made With Recycled Cardboard : No
• Packaging Without Single Use Plastic : No
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Take-Back : No
• Sustainable Packaging : No
• Eu Rohs Directive : Not compliant
• Complementary
• Height : 308.9 mm
• Breaking Capacity : 50 kA
• Connections - Terminals : I-Line line || lugs ground AWG 6 copper 4 N.m || lugs neutral AWG 6 copper 4 N.m
• Mounting Support : panel mounting
• Cable Length : 483 mm
• Provided Equipment : alarm enable/disable switch || surge counter || circuit-breaker
• Surge Current : 120 kA
• Phase : 3 phase
• Local Signalling : status LED green per phase normal operation || status LED red per phase fault
• Short-Circuit Protection : 200 kA
• [Uc] Maximum Continuous Operating Voltage : 150 V
• Line Rated Current : 60 A
• Width : 341.9 mm
• Wiring Configuration : 4-wire
• Depth : 142.1 mm
• Trip Unit Technology : thermal-magnetic
• Number Of Poles : 3
• [Ue] Rated Operational Voltage : 208Y/120 V AC
• Specifications
• Country of Origin : Mexico
• Length : 483 mm
• Width : 341.9 mm
• Height : 308.9 mm
• Range Of Product : Surgelogic
• Breaking Capacity Code : HL
• Product Or Component Type : surge protection device
• Device Short Name : IMA
