Linergy power distribution blocks are for terminating wires and are designed to NEMA standards. This three pole block has two lug openings on the line (main) side and twelve lug openings on the load (branch) side. The line side lug is rated to accept one #6 to 500 kcmil copper wire. The load side lug is rated to accept one #14 to 2 copper wire. The lugs are made of copper. The lugs are rated for 760 amperes with copper wire. The lugs are rated to 600 volts. The housing is made of general purpose phenolic. These Linergy power distribution blocks are UL component recognized and CSA certified.

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Environment
• Product Certifications : UL recognized E60616 CCN XCFR2 || CE || CSA file 70361 class 6228 01
• Contractual warranty
• Warranty : 18 months
• Environmental data
• Rohs Exemption Information : Yes
• Packaging Made With Recycled Cardboard : Yes
• Mercury Free : Yes
• Packaging Without Single Use Plastic : No
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Toxic Heavy Metal Free : Yes
• Reach Regulation : Free of Substances of Very High Concern above the threshold
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Reach Free Of Svhc : Yes
• Take-Back : No
• Sustainable Packaging : No
• Eu Rohs Directive : Compliant
• Complementary
• [Ics] Rated Service Breaking Capacity : 100 kA UL 508 A
• Ambient Air Temperature For Operation : -40-302 °F
• Height : 5.5 in
• Mounting Support : surface mount
• Electrical Connection : tin plated copper lugs
• Connections - Terminals : load lug 40 lbf.in AWG 8 copper || load lug 35 lbf.in AWG 14...AWG 10 copper || line lug 375 lbf.in AWG 4...500 kcmil copper || load lug 50 lbf.in AWG 2 copper || load lug 45 lbf.in AWG 6...AWG 4 copper
• Wire Stripping Length : load: 1 in for bottom connection || line: 1.63 in || load: 0.63 in for top connection
• Number Of Cables : line 2 , AWG 4...500 kcmil, copper || load 12 , AWG 14...AWG 2, copper
• Material : phenolic: block
• Width : 3.17 in
• Depth : 3.13 in
• Product Compatibility : 9080LB53
• Number Of Poles : 3
• [Ue] Rated Operational Voltage : 600 V AC/DC
• Number Of Terminals : 12 line || 3 load
• Specifications
• Country of Origin : United States
• Width : 3.17 in
• Height : 5.5 in
• Range Of Product : 9080LB
• Product Or Component Type : Power Distribution Block
• Line Rated Current : 760-760 A copper
