PASS & SEYMOUR

Turnlok® SteriGuard™ Antimicrobial Connector 20A, 3Φ250V

TLCN IP67 20A 3PH 250V L1520R

PSS27W75AM 27W75AM 785007057287
156.75 / EA
http://schema.org/OutOfStock
Mayer-DDS-Turnlok® SteriGuard™ Antimicrobial Connector 20A, 3Φ250V-1
  • Amperage: 20 A
  • Applications: Industrial
  • Country of Origin: USA
  • Depth: 4.03 in
  • Height: 1.85 in
  • Indoor/Outdoor: Indoor
  • Number of Poles: 3
  • Number of Wires: 4
  • Type: Connector
  • Voltage: 250.0 V
  • Warranty Length: 1 yr
  • Width: 1.85 in
SteriGuard Anti-Microbial Wiring Devices provide excellent protection against the growth of microbes on all surfaces. Independent testing proves the ability of these devices to inhibit the growth of Escherichia coli, Gram (-) and Staphylococcus aureus, Gram (+) providing long lasting benefits to manufacturers beyond conventional cleaning methods. Rated watertight for 1,500 psi high-pressure
QTY
  • Product Description
  • Features
  • Specifications
SteriGuard Anti-Microbial Wiring Devices provide excellent protection against the growth of microbes on all surfaces. Independent testing proves the ability of these devices to inhibit the growth of Escherichia coli, Gram (-) and Staphylococcus aureus, Gram (+) providing long lasting benefits to manufacturers beyond conventional cleaning methods. Rated watertight for 1,500 psi high-pressure
  • Features
    • UL and CSA Listed
    • NSF (National Sanitation Foundation) Certified
    • Patent Pending
    • Anti-microbial Additives Embedded in polymer and inhibits Growth of Bacteria, Molds, Mildews and Fungi
    • Anti-microbial Additive Resistant to Scuffing and Cleaning
    • Escherichia (E.Coli): - Log reduction greater than 4.8, reduced surface bacteria by greater than 99.99%
    • Staphylococcus (Staph), MRSA: - Log Reduction greater than 4.3, reduces surface bacteria by greater than 99.97%
    • Salmonella : Log Reduction Greater Than 3.6, reduces surface bacteria by Greater Than 99.97%
    • RoHS Compliant (Non-Halogenated)
    • Independently tested and Certified to JIS Z2801 standards
    • Resistant to High Pressure Hose-down applications
    • Tongue & Groove Environmental Sealing
    • Keyed Body and Cover for Alignment
    • NEMA Type 4, 4x, 6, 6P and IP67 Protection
    • Steriguard: Anti-microbial Wiring Devices are ideal for a wide range of applications including food and beverage preparation, procession, & packaging: agriculture, pharmaceutical, and health care.
  • Specifications
    • Depth : 4.03 in
    • Height : 1.85 in
    • Special Features : Rated watertight for 1,500 psi high-pressure hosedown, P&S Turnlok® watertight plugs & connectors feature rugged construction, multiple seals to ensure protection against the environment and ease of installation.
    • Flanged : No
    • Width : 1.85 in
    • Type : Connector
    • Country of Origin : United States
    • Amperage : 20.0 A
    • Voltage : 250.0 V
    • Standard : UL Listed
    • Number of Wires : 4.0
    • Standard : CSA Listed
    • Number of Phases : 3.0
    • Warranty Type : 1-Year
    • Indoor/Outdoor : Indoor
    • Number of Poles : 3-Way
    • Connector Style : Locking
    • Application Sector : Industrial
    • NEMA Configuration Code : L15-20R
    • Features : Antimicrobial Protection
    • Environmental Conditions : Moisture Resistance NEMA 4, 4X, 12, 6, 6P/IP65, 66, 67 (Plug & Connector only) Flammability UL94V0 (boxes & wiring device interiors) Operating Temperature -40°C (without impact) to +60°C continuous UV resistance All exposed material s are UV stabilized
    • Color : Yellow
    • Product Line : Pass & Seymour
    • Terminal Accommodation : #14 AWG - #10 AWG
