Designed for plug-in EV charging applications, Hubbell’s 14-50R receptacle is a premium and dependable solution to exceed the requirements of electric vehicle owners. This receptacle ensures a safe and efficient charging experience, providing peace of mind to EV users.

• Features
• Tailored for EV Charging: This receptacle is purpose-built to cater to the specific needs of EV charging. It incorporates features and specifications that are optimized for the safe and efficient charging of electric vehicles.
• Industrial-Grade Construction: This EV receptacle boasts a robust and durable construction. It is engineered using high quality materials that can withstand demanding environments, ensuring long-lasting performance and reliability.
• Secure Connection: Terminal box shields against loose wires and external damage with a durable enclosure. Features a clamping mechanism for tight, efficient wire termination, reducing power loss or overheating risks.
• Contact Force & Durability: Thick wall terminal box offers 50% greater contact force for secure connections, minimizing power interruptions. Designed for heavy use, it withstands frequent insertions and removals, ensuring lasting performance.
• Fast & Efficient Charging: Features a 3-pole, 4-wire grounding for secure EV charging, minimizing electrical faults. With a 50A, 125/250V rating, it ensures high-power, faster charging times, promoting safety and efficiency.
• Effortless Installation: This EV Charging Receptacle is designed for easy setup, featuring a straightforward wiring mechanism suitable for both professional electricians and DIY enthusiasts, ensuring a hassle-free installation process.
• Standard

• Specifications
• Buy American Compliant : Yes
• Country of Origin : US
• Current / Amperage Rating : 50 A
• Dimensions : 3.28 in x 2.25 in x 2.23 in
• Each - Width : 2.500 in
• Height : 2.23 in
• Horsepower - Maximum : 3
• Industry Standard(s) : UL, CSA, Fed Spec
• Length : 3.28 in
• Performance : Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-0;Environmental - IP Suitability - IP20;Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
• Amperage Rating : 50 A
• Application : Heavy Duty
• Color : Noir
• Dielectric Strength : Withstands 2,000V minimum
• Environmental Conditions : Indoor Dry Unless Protected By Additional Means
• NEMA Rating : 6-50R
• Number of Poles : 2-Pole
• Number of Wires : 3-Wire Grounding
• Phase : Single Phase
• Size : 3.28 in x 2.25 in x 2.23 in
• Special Features : Standard
• Standard : UL, CSA, Fed Spec
• Type : Receptacle
• Voltage Rating : 250 V
• Wattage : 12500 W
• Wire Size : #12 AWG to #4 AWG
• Voltage Rating Description : 250 V
• Width : 2.25 in
• Connectivity : Back and Side Wired Screw Terminals
• Display Size : Standard Sized Product
• Nema Rating : 6-50R
• Number Of Poles : 2-Pole
• Number Of Wires : 3-Wire Grounding
• Operating Temperature : Maximum continuous 75°C and minimum -40°C without Impact
• Weight : 0.45 lb.
• Class Code : A04
• Description - Invoice : RCPT, 2P3W, 50A 250V, 6-50R, BK
• Freight Class Code : 06168002
• Harmonization Code : 8536690200
• Image Actual Or Representative : A
• MSDS Flag : No
• Replaced Catalog Number : 9367
• Sub Class Code : A04A080
• Material - Mounting Hardware : Screw Mounting
• Current Rating : 50 A
• Material : Thermoplastic/Composite
• Base Unit of Measure : EA
• BOX SIZE : 5.800x8.500x6.900 (in)
• Carton - Gross Weight per Pack : 4.750 lb.
• Carton - Number of Sub Packs : 10
• Carton - Pack Description : Carton
• Carton - SCC-14 Next Lower Level Sub Pack : 783585015279
• Carton - Total Units : 10 EA
• Case Weight : 4.650 lb.
• Each - Pack Description : Each
• Lowest Level UOM : Each
• Pallet - GTIN - Package : 70783585015278
• Pallet Height : 47.200 in
• Pallet Length : 48.000 in
• Pallet Weight : 1164.800 lb.
• Pallet Width : 40.000 in
• Certifications
• EU RoHS Indicator : Yes
