Single Receptacle

RECPT 30A 277V 2P 3W

HUBHBL9315 HBL9315 783585015514
65.85 / EA
http://schema.org/OutOfStock
Mayer-DDS-Single Receptacle-1
  • Operating Temperature: -40 °C, 75 °C
  • Voltage: 2,000 V
QTY
  • Features
  • Specifications
  • Features
    • Sequenced contacts assure protection
    • Catalog number, ratings and certifications molded in face
    • One piece design power and ground contacts
  • Listings
    • UL Listed File E2186
    • CSA Certified
    • NEMA® WD-6 Compliant
  • Ordering Information
    • Description : Receptacle, black, RTP
    • Device Color : Black
  • Electrical
    • Current Interrupting : Certified for current interrupting at full rated current
    • Dielectric Voltage : Withstands 2,000V minimum
  • Mechanical
    • Product Identification : Ratings are a permanent part of the device
    • Terminal Accommodation : #12 AWG through #4 AWG copper wire only
    • Terminal Identification : Terminals identified in accordance with UL 498 and CSA
  • Environmental
    • Flammability : UL 94 V-0
    • IP Suitability : IP20
    • Operating Temperatures : Maximum continuous 75°C; minimum -40°C (w/o impact)
  • Specifications
    • Housing : Reinforced Thermoplastic Polyester
    • Mounting Plate : .062 in. (1.5) Pre-Plated Steel
    • Contacts : Brass
    • Ground Shunt : Brass
    • Box Terminals : Copper
  • Complementary Products
    • Wallplate or Weatherproof Cover : 2.16" Opening
