SNAP5362ITRA

S-CONNECT DUP 20A/125V TR IV

HUBSNAP5362ITRA SNAP5362ITRA 783585552996
28.94 / EA
http://schema.org/OutOfStock
Mayer-DDS-SNAP5362ITRA-1
  • Amperage: 20 A
  • Current: 20 A
  • Length: 3.28 in
  • Material: Nylon
  • NEMA: 5-20R
  • Number of Phases: 1
  • Number of Poles: 2
  • Number of Wires: 3
  • Operating Temperature: -40 °C, 75 °C
  • Quantity: 10
  • Style: Smooth Face Finder Groove Face
  • Voltage: 125 V
  • Wattage: 2500 W
  • Width: 1.64 in
  • Wire Size: 12 AWG
Straight Blade Devices, Receptacles, Tamper Resistant, Decorator Duplex, SNAPConnect 2, 20A 125V, 2-Pole 3- Wire Grounding, 5-20R, Ivory.
QTY
  • Product Description
  • Features
  • Specifications
Straight Blade Devices, Receptacles, Tamper Resistant, Decorator Duplex, SNAPConnect 2, 20A 125V, 2-Pole 3- Wire Grounding, 5-20R, Ivory.
  • Performance
    • Electrical - Current Interrupting - Receptacle certified for current interrupting at full rated current with equivalently rated NEMA® plug
    • Electrical - Dielectric Voltage - Withstands 2,000V minimum
    • Environmental - Flammability - UL 94 V-2
    • Environmental - Operating Temperature - Maximum continuous 75°C, minimum -40°C (without impact)
    • Mechanical - Product Identification - Ratings are a permanent part of the device
    • Mechanical - Terminal Identification - Terminal wire leads identified in accordance with UL 498
  • Industry Standard(s)
    • Certified to CSA, C22.2, No. 42 File 285
    • Fed. Spec. W-C-596
    • NEMA® WD-6 Compliant
    • UL Listed to UL498 File No. E2186
  • Features
    • Audible SNAP, indicates solid connection
    • Reduces installation time
    • Quick Connect- SNAPConnect, Tamper-Resistant, USA Product, Quick Connect- SNAPConnect, USA Product
    • Fully insulated design
  • Specifications
    • Application : Extra Heavy Duty Specification Grade
    • Color : Ivory Gray
    • Environmental Conditions : Indoor Dry Unless Protected By Additional Means
    • Horsepower - Maximum : 1
    • Item Type : Traditional Duplex
    • Material : Nylon
    • Material - Mounting Hardware : Screw Mounting
    • Number Of Poles : 2-Pole
    • OEM Brand Name : Hubbell Wiring Device-Kellems
    • Operating Temperature : Maximum continuous 75°C and minimum -40°C without Impact
    • Series : Extra Heavy Duty
    • Style : Smooth Face Finder Groove Face
    • Type : Standard Duplex
    • UPC : 783585552996
    • Dimensions : 3.28 in x 1.56 in x 1.1 in
    • Display Size : Standard Sized Product
    • Length : 3.28 in
    • Width : 1.64 in
    • Amperage Rating : 20 A
    • Connectivity : Connectorized
    • Current / Amperage Rating : 20 A
    • Current Rating : 20 A
    • Dielectric Strength : Withstands 2,000V minimum
    • Phase : Single Phase
    • Voltage Rating : 125 V
    • Voltage Rating Description : 125 V
    • Wattage : 2500 W
    • Number Of Wires : 3-Wire
    • Wire Size : #12 AWG
    • Nema Rating : 5-20R
    • Carton Quantity : 10 EA
