ADVANCE

MAG BALLAST (1)F20T12 PH 120V

BALLAST - 1 20T12PH 118

ADVLC1420CI LC1420CI 781087101308
42.89 / EA
http://schema.org/OutOfStock
MAG BALLAST (1)F20T12 PH 120V
  • Country of Origin: USA
  • Height: 1.810 in
  • Length: 3.060 in
  • Voltage: 120 V
  • Weight: 0.800 lb
  • Width: 1.590 in
Available for many fluorescent lamp types sold today, including Preheat, Rapid Start, 2-pin CFL, Slimline, High Output, Very High Output and Circline. Magnetic ballasts can be used in any application where these lamps are used.
QTY
  • Features
  • Specifications
  • Certifications and Standards
    • EU RoHS
    • ARRA
    • BAA
  • Specifications
    • Country of Origin : USA
    • Weight : 0.800 Lbs
    • Height : 1.8100 IN
    • Width : 1.5900 IN
    • Length : 3.0600 IN
    • Ballast Factor : 0.93
    • Brand Name : Signify Electronics
    • Frequency Rating : 60 HZ
    • Lamp Type : T12
    • Number Of Lamps : 1
    • Power Factor : NORMAL
    • Special Features : UL, CSA, RoHS
    • Start Type : PREHEAT
    • Total Harmonic Distortion : 10
    • Type : Magnetic Fluorescent
    • Voltage Rating : 120 V
    • Wattage : 20 WTT
    • Housing Material : Metal
    • Wire Type : Solid
    • Wire Gauge : 18 AWG
    • Efficacy : 4.5
