VNTC – PVC / Nylon Insulation – PVC Jacket – 16 AWG #A21602

16GA 1PR 600V SHL D TC

OMIA21602 A21602 OMIA21602
0.00 / EA
http://schema.org/OutOfStock
Mayer-DDS-VNTC – PVC / Nylon Insulation – PVC Jacket – 16 AWG #A21602-1
  • Cable Type: Tray Cable
  • Gauge: 16 AWG
  • Jacket Color: Black
  • Jacket Material: Polyvinyl Chloride, PVC
  • Outside Diameter: 0.3 in
  • Temperature Rating: 90 °C
  • Type: Simple
This shielded 16 AWG tray cable has a PVC jacket, a PVC/nylon insulation, and uses the E-2 color code
QTY
  • Product Description
  • Specifications
This shielded 16 AWG tray cable has a PVC jacket, a PVC/nylon insulation, and uses the E-2 color code
  • Specifications
    • Cable Type : Tray Cable
    • Conductor Material : Bare Copper
    • Conductors : 2
    • Drain Wire : Stranded, tinned copper
    • Gauge : 16
    • Insulation Material : PVC/Nylon - Polyvinyl Chloride/Nylon
    • Item Class : TCA2
    • Jacket Color : Black
    • Jacket Material : PVC - Polyvinyl Chloride
    • Jacket Thickness : 0.045
    • Material Weight : 51
    • Outside Diameter Inches : 0.3
    • Product Type : Simple
    • Shield : Aluminum/polymer tape
    • Shield Search : Yes
    • Temperature : 90C
    • Unit Of Measure : ft
    • Voltage Search : 600V
    • Weight : 1
