This is a soft membrane cable entry type FL21, designed for electrical enclosures, featuring 7 cable entry points. The product is made of TPE (thermoplastic elastomer). It is designed to be installed on the cable gland plate adapter or directly on enclosure. The external height,width and depth are 40mm, 194mm and 88mm respectively. The product contains a membrane and the fixing elements. It´s color is grey RAL7035. The operational temperature range covers -40° to +100 °C. It meets the V0 flame retardance standard according to UL 94. Additionally, it has an IP66 rating for ingress protection.

• Physical Attributes
• Color : Gray RAL 7035)
• Important Information Attributes
• Persona Type Ids : LC, OM, OM8, PB, SI
• Persona Type Names : Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
• Market Segmentation Id : COMMERCIAL, INDUSTRIAL
• Market Segmentation : Commercial, Industrial
• Cable Entry Number : 2 x 24-54 mm, 1 x 30-60 mm, 4 x 10-14 mm, 7
• Device Composition : 1 membrane, 1 fixing elements
• Environmental Characteristic : oil resistant UL 157 FIMKO, UV resistant, weatherproof, fire resistance UL 94 V0
• Fixing Mode : by fixing element
• Flame Retardance : V0 conforming to UL 94
• Material : TPE (thermoplastic elastomer)
• Local Data Status : Publishable
• Local Publishable Date : 2026-04-13
• Return Indicator : N
• Stocking Flag : Y
• Stock Policy : 2
• Weee Scope : Out
• Scope Perimeter : At least in Europe
• Eoli Availability Display : No need of specific recycling operations
• Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
• Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
• Rohs Eur In Scope : No
• Rohs Eur Status : Compliant
• Rohs Eur Conformity Date : 1916
• Rohs Eur Full Compliance Status : Compliant
• China Rohs In Scope : No
• China Rohs Label : 1
• With Recycled Cardboard : No
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Tier Id : 2
• Tier : 2
• Function Option Id : STANDARD
• Function Option : Standard
• Product Kit Identifier : N
• Device Application : multi-purpose
• Energy Efficiency Optimized : False
• Mounting Support : cable gland plate
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : cable entry membrane
• Quantity Per Set : set of 1
• Range : PanelSeT
• Returnability : No
• Sustainable Packaging : No
• Accessory Separate Part Category : cable management accessory
• Warranty In Months : 18
• Pep Code : ENVPEP1001004EN
• Offer Owner Code : 190789
• Pn : 1
• Height Nominal : 40 mm
• Height Useful : 40 mm
• Width Nominal : external: 214 mm
• Width Real : fixing center: 194 mm
• Environment Attributes Main
• China Rohs Regulation : Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
• Ambient Air Temperature For Operation : -40-100 °C, -40-100 °C
• Ip Degree Of Protection : IP66
• Take Back : No
• Reach Free Shvc : Yes
• Recycled Metal Content At Cr Level : 0 %
• Toxic Heavy Metal Free : Yes
• Mercury Free : Yes
• Environmental Disclosure : ENVPEP1001004EN
• Eu Rohs Directive : Compliant
• Packaging Made With Recycled Cardboard : No
• Packaging Without Single Use Plastic : No
• Reach Free Of Svhc : Yes
• Reach Regulation : Free of Substances of Very High Concern above the threshold
• Pep Code : ENVPEP1001004EN
• General Attributes
• Product Or Component Type : cable entry membrane
• ETIM
• ETIM 8 : EC000211
• ETIM 9 : EC000211
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Country of Origin : France
• Height : 1.57 in
• Width : 7.64 in
