Climasys CC - electronic hygrostat - 200…240 V - Hr 20…80% - OLED screen

HYGROSTAT HS300

SQDNSYCCOHY230VID NSYCCOHY230VID 3606480152634
268.11 / EA
http://schema.org/OutOfStock
Mayer-DDS-Climasys CC - electronic hygrostat - 200…240 V - Hr 20…80% - OLED screen-2
  • Country of Origin: China
  • Depth: 0 in
  • Height: 3.35 in
  • Warranty Length: 18 mth
  • Width: 2.2 in
Climasys CC electronic hygrostat with OLED screen. H is 85 x W is 56 x D is 44 mm. Displays relative humidity. 6 terminals 2.5 mm² electric connection. 2 outputs heating function. Input voltage is 200 to 240V. Humidity Range is 20…80%. Hysteresis 3 %. Po
QTY
  • Product Description
  • Features
  • Specifications
Climasys CC electronic hygrostat with OLED screen. H is 85 x W is 56 x D is 44 mm. Displays relative humidity. 6 terminals 2.5 mm² electric connection. 2 outputs heating function. Input voltage is 200 to 240V. Humidity Range is 20…80%. Hysteresis 3 %. Po
  • CAD
    • https://download.schneider-electric.com/files?p_Doc_Ref=MCADUE0003252_3D-CAD&p_File_name=MCADUE0003252_3D-simplified.stp
    • https://download.schneider-electric.com/files?p_Doc_Ref=MCADUE0003252_3D-CAD&p_File_name=MCADUE0003252_2D-back.dwg
    • https://downlo
  • Electrical Connection
    • 6 terminals 2.5 mm²
  • Market Segmentation
    • Commercial
    • Industrial
  • Persona Type Names
    • Contractor
    • Original Equipment Manufacturer
    • OEM - Control Panelbuilder
    • Panel Builder
    • System Integrator
  • Flame Retardance
    • self-extinguishing conforming to UL94 (material V0)
  • Number Of Outputs
    • 2 heating function
  • Persona Type Ids
    • LC
    • OM
    • OM8
    • PB
    • SI
  • Input Voltage
    • 200...240 V AC
  • Market Segmentation Id
    • COMMERCIAL
    • INDUSTRIAL
  • Maximum Switching Capacity
    • 4 A 230 V AC
  • Important Information Attributes
    • Local Data Status : Publishable
    • Local Publishable Date : 2024-02-10
    • Legacy WEEE Scope : In
    • WEEE Product Category : 5
    • Scope Perimeter : At least in Europe
    • EOLI Availability Display : No need of specific recycling operations
    • Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
    • Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : Yes
    • ROHS EUR Status : Compliant
    • ROHS EUR Conformity Date : 627
    • ROHS EUR Full Compliance Status : Compliant
    • ROHS EUR Full Compliance Status Id : COMPLIANT
    • China ROHS In Scope : No
    • China ROHS Label : 1
    • Green Premium Status For Reporting : Green Premium product
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Return Indicator : N
    • WD Status : 1 - GSC certified
    • Tier Id : 2
    • Tier : 2
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Hysteresis : 3 %
    • Package Weight Lbs : 154.000 g
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : electronic hygrostat
    • Range : ClimaSys
    • Returnability : No
    • Sustainable Packaging : No
    • Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • Relationship Type : cross-selling relationship
    • Pep Code : ENVPEP2103012EN
  • General Attributes
    • Product Or Component Type : electronic hygrostat
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=10178511&lang=en-us
    • Take Back : No
    • Reach Free SHVC : Yes
    • China ROHS Regulation : Pro-active China RoHS declaration (out of China RoHS legal scope)
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP2103012EN
    • EU ROHS Directive : Compliant
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Free Of SVHC : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP2103012EN
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Country of Origin : China
    • Height : 3.35 in
    • Width : 2.2 in
    • Depth : 0 in
