ClimaSys CV Axial motor ventilator. 230V 50Hz or 60Hz. 68 W 50 Hz, 85 W 60 Hz. Free flow rate of 550 m3/h at 50 Hz and 60 Hz. 336 x 316 x 161 mm. Cut-out dimensions of 291 x 291 mm. Outlet grille injected thermoplastic (ASA PC), Grey RAL 7035. Connection

• Power Range
• 64 W 50 Hz
• 80 W 60 Hz
• CAD
• https://download.schneider-electric.com/files?p_Doc_Ref=DB300474&p_File_name=DB300474.dwg
• https://download.schneider-electric.com/files?p_Doc_Ref=DB300474&p_File_name=DB300474.dxf
• https://download.schneider-electric.com/files?p_Doc_Ref=MCADUE0000292_3D
• Range Compatibility
• Prisma P
• Prisma G
• Maximum Pressure
• 140 Pa flow rate 0 m³/h
• Carbon Footprint Of The Installation Phase A5
• 0.39496963024347537
• 0.4 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4
• 5 kg CO2 eq.
• 5.30078982792936
• Condition Of Use
• filter must be cleaned and replaced regularly
• surrounding environment must be relatively clean
• outside temperature must be 5 °C lower than inside temperature
• overfrequent filter replacement should be avoided
• flow rates depends on the work point,
• Material
• outlet grille injected thermoplastic (ASA PC)
• Carbon Footprint Of The Manufacturing Phase A1 To A3
• 23 kg CO2 eq.
• 23.080254847458853
• Accessories
• NSYCVF550M230FB
• NSYCVF575M230MF
• NSYCAAPV
• NSYDPA3
• NSYCAP291LZF
• NSYCAP291LXF
• NSYCAF291L55
• NSYCAF190
• NSYCAF291T
• NSYCAG130X110LM
• Market Segmentation
• Commercial
• Industrial
• Persona Type Names
• Contractor
• Original Equipment Manufacturer
• OEM - Control Panelbuilder
• Panel Builder
• System Integrator
• Device Composition
• 1 axial motor
• 2 protective grille on the front and rear surfaces
• 1 filter front of axial motor
• 1 filter fron
• Carbon Footprint Of The Use Phase B2 B3 B4 B6
• 0 kg CO2 eq.
• 0
• Line Rated Current
• 0.29-0.29 A 50 Hz
• 0.35-0.35 A 60 Hz
• Persona Type Ids
• LC
• OM
• OM8
• PB
• SI
• Input Voltage
• 230 V 50/60 Hz
• Air Flow
• free flow rate with standard filter: 562 m3/h at 50 Hz
• free flow rate with standard filter: 586 m3/h at 60 Hz
• free flow rate with standard filte
• Carbon Footprint Of The Distribution Phase A4
• 7.0433652949549135
• 7 kg CO2 eq.
• Market Segmentation Id
• COMMERCIAL
• INDUSTRIAL
• Color
• outlet grille Gray RAL 7035)

• Conformance Attributes
• Product Certifications : CSA
• Complementary Attributes
• US Rated Supply Voltage : 207...244 V
• Important Information Attributes
• Local Data Status : Publishable
• Local Publishable Date : 2025-07-09
• Manufacturing Carbon Footprint : 23.0802548474589
• Distribution Carbon Footprint : 7.04336529495491
• Installation Carbon Footprint : 0.394969630243475
• Use Carbon Footprint : 0
• End Of Life Carbon Footprint : 5.30078982792936
• Legacy WEEE Scope : In
• WEEE Product Category : 5
• Scope Perimeter : At least in Europe
• EOLI Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1107017EN
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• ROHS EUR In Scope : Yes
• ROHS EUR Status : Compliant with Exemptions
• ROHS EUR Conformity Date : 1916
• ROHS EUR Full Compliance Status : Compliant with Exemptions
• ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
• China ROHS In Scope : No
• Green Premium Status For Reporting : Green Premium product
• With Recycled Cardboard : No
• Without Single Use Plastic : No
• Return Indicator : N
• WD Status : 1 - GSC certified
• Tier Id : 2
• Tier : 2
• Function Option Id : STANDARD
• Function Option : Standard
• Bearing Type : ball
• Package Weight Lbs : 3.554 kg
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : fan
• Range : ClimaSys
• Returnability : No
• Sustainable Packaging : No
• Total Lifecycle Carbon Footprint : 36 kg CO2 eq.
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Carbon Footprint Kg Co2 Eq Total Life Cycle : 35.8193796005866
• Relationship Type : Compatible relationship
• Pep Code : ENVPEP110717EN
• Pep Verification Date : 2025-08-05
• PCR Version : PEP-PCR-ed4-2021 09 06
• PSR Version : PSR-0008-ed3-EN-2023 10 19
• Type Of Verification For The Pep : Independent external review
• Product Weight In G : 3554
• Functional Unit Description : "Transfer 1 m3 of air per hour for the ventilation and air treatment and smoke exhaust and filtration of a building/Confined space over the reference lifetime of 17 years. "
• Functional Unit Quantity : 1
• Functional Unit Unit : unit
• Reference Lifetime In Y : 17
• Energy Consumption On Product Lifetime In Kwh : 0
• Energy Model Manufacturing A1 A3 : Electricity Mix; Low voltage; 2020; France, FR
• Energy Model Installation A5 : No energy used
• Energy Model Use B6 : Electricity Mix; Low voltage; 2020; Europe, EU-27
• Energy Model End Of Life C1 C4 : Global, European and French datasets are used.
• Recyclability Potential In : 64
• Acidification Ap Mole Of H Equiv Total Life Cycle : 0.26271871435032396
• Acidification Ap Mole Of H Equiv Manufacturing A1 A3 : 0.215306252825855
• Acidification Ap Mole Of H Equiv Distribution A4 : 0.028976842986287974
• Acidification Ap Mole Of H Equiv Installation A5 : 0.0011573703544680292
• Acidification Ap Mole Of H Equiv Maintenance B2 : 0
• Acidification Ap Mole Of H Equiv Repair B3 : 0
• Acidification Ap Mole Of H Equiv Replacement B4 : 0
• Acidification Ap Mole Of H Equiv Operational Energy Use B6 : 0
• Acidification Ap Mole Of H Equiv End Of Life C1 C4 : 0.017278248183712954
• Acidification Ap Mole Of H Equiv Benefits Loads Beyond System Boundaries D : -0.12700357420904565
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Total Life Cycle : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Manufacturing A1 A3 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Distribution A4 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Installation A5 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Maintenance B2 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Repair B3 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Replacement B4 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Operational Energy Use B6 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C End Of Life C1 C4 : 0
• Biogenic Carbon Content Of The Associated Packaging Kg Of C Benefits Loads Beyond System Boundaries D : 0
• Biogenic Carbon Content Of The Product Kg Of C Total Life Cycle : 0
• Biogenic Carbon Content Of The Product Kg Of C Manufacturing A1 A3 : 0
• Biogenic Carbon Content Of The Product Kg Of C Distribution A4 : 0
• Biogenic Carbon Content Of The Product Kg Of C Installation A5 : 0
• Biogenic Carbon Content Of The Product Kg Of C Maintenance B2 : 0
• Biogenic Carbon Content Of The Product Kg Of C Repair B3 : 0
• Biogenic Carbon Content Of The Product Kg Of C Replacement B4 : 0
• Biogenic Carbon Content Of The Product Kg Of C Operational Energy Use B6 : 0
• Biogenic Carbon Content Of The Product Kg Of C End Of Life C1 C4 : 0
• Biogenic Carbon Content Of The Product Kg Of C Benefits Loads Beyond System Boundaries D : 0
• Climate Change Biogenics Kg Co2 Eq Total Life Cycle : -0.10110247039471924
• Climate Change Biogenics Kg Co2 Eq Manufacturing A1 A3 : -0.1444338267266274
• Climate Change Biogenics Kg Co2 Eq Distribution A4 : 0
• Climate Change Biogenics Kg Co2 Eq Installation A5 : 0.01876096794829217
• Climate Change Biogenics Kg Co2 Eq Maintenance B2 : 0
• Climate Change Biogenics Kg Co2 Eq Repair B3 : 0
• Climate Change Biogenics Kg Co2 Eq Replacement B4 : 0
• Climate Change Biogenics Kg Co2 Eq Operational Energy Use B6 : 0
• Climate Change Biogenics Kg Co2 Eq End Of Life C1 C4 : 0.024570388383615985
• Climate Change Biogenics Kg Co2 Eq Benefits Loads Beyond System Boundaries D : 0.09279898534722131
• Climate Change Fossil Fuels Kg Co2 Eq Total Life Cycle : 35.919552396660826
• Climate Change Fossil Fuels Kg Co2 Eq Manufacturing A1 A3 : 23.22376000356936
• Climate Change Fossil Fuels Kg Co2 Eq Distribution A4 : 7.0433652949549135
• Climate Change Fossil Fuels Kg Co2 Eq Installation A5 : 0.37620866229518324
• Climate Change Fossil Fuels Kg Co2 Eq Maintenance B2 : 0
• Climate Change Fossil Fuels Kg Co2 Eq Repair B3 : 0
• Climate Change Fossil Fuels Kg Co2 Eq Replacement B4 : 0
• Climate Change Fossil Fuels Kg Co2 Eq Operational Energy Use B6 : 0
• Climate Change Fossil Fuels Kg Co2 Eq End Of Life C1 C4 : 5.276218435841367
• Climate Change Fossil Fuels Kg Co2 Eq Benefits Loads Beyond System Boundaries D : -14.453084654092244
• Climate Change Total Kg Co2 Eq Total Life Cycle : 35.8193796005866
• Climate Change Total Kg Co2 Eq Manufacturing A1 A3 : 23.080254847458853
• Climate Change Total Kg Co2 Eq Distribution A4 : 7.0433652949549135
• Climate Change Total Kg Co2 Eq Installation A5 : 0.39496963024347537
• Climate Change Total Kg Co2 Eq Maintenance B2 : 0
• Climate Change Total Kg Co2 Eq Repair B3 : 0
• Climate Change Total Kg Co2 Eq Replacement B4 : 0
• Climate Change Total Kg Co2 Eq Operational Energy Use B6 : 0
• Climate Change Total Kg Co2 Eq End Of Life C1 C4 : 5.30078982792936
• Climate Change Total Kg Co2 Eq Benefits Loads Beyond System Boundaries D : -14.360285668745023
• Components For Re Use Kg Total Life Cycle : 0
• Components For Re Use Kg Manufacturing A1 A3 : 0
• Components For Re Use Kg Distribution A4 : 0
• Components For Re Use Kg Installation A5 : 0
• Components For Re Use Kg Maintenance B2 : 0
• Components For Re Use Kg Repair B3 : 0
• Components For Re Use Kg Replacement B4 : 0
• Components For Re Use Kg Operational Energy Use B6 : 0
• Components For Re Use Kg End Of Life C1 C4 : 0
• Components For Re Use Kg Benefits Loads Beyond System Boundaries D : 0
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Total Life Cycle : 0.002211378925799748
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Manufacturing A1 A3 : 0.002211010595193411
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Distribution A4 : 0.00000000060359990023
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Installation A5 : 0.00000000971726285811
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Maintenance B2 : 0
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Repair B3 : 0
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Replacement B4 : 0
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Operational Energy Use B6 : 0
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb End Of Life C1 C4 : 0.00000035800974357882
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Benefits Loads Beyond System Boundaries D : -0.0017847887974588392
• Depletion Of Abiotic Resources Fossil Fuels Mj Total Life Cycle : 610.8498921669001
• Depletion Of Abiotic Resources Fossil Fuels Mj Manufacturing A1 A3 : 472.5077407555051
• Depletion Of Abiotic Resources Fossil Fuels Mj Distribution A4 : 87.37267616230378
• Depletion Of Abiotic Resources Fossil Fuels Mj Installation A5 : 3.9177811496063017
• Depletion Of Abiotic Resources Fossil Fuels Mj Maintenance B2 : 0
• Depletion Of Abiotic Resources Fossil Fuels Mj Repair B3 : 0
• Depletion Of Abiotic Resources Fossil Fuels Mj Replacement B4 : 0
• Depletion Of Abiotic Resources Fossil Fuels Mj Operational Energy Use B6 : 0
• Depletion Of Abiotic Resources Fossil Fuels Mj End Of Life C1 C4 : 47.05169409948498
• Depletion Of Abiotic Resources Fossil Fuels Mj Benefits Loads Beyond System Boundaries D : -243.61198863748976
• Ecotoxicity Fresh Water Ctue Total Life Cycle : 699.8975581154543
• Ecotoxicity Fresh Water Ctue Manufacturing A1 A3 : 593.1568908321071
• Ecotoxicity Fresh Water Ctue Distribution A4 : 57.15120851233086
• Ecotoxicity Fresh Water Ctue Installation A5 : 5.354364973078746
• Ecotoxicity Fresh Water Ctue Maintenance B2 : 0
• Ecotoxicity Fresh Water Ctue Repair B3 : 0
• Ecotoxicity Fresh Water Ctue Replacement B4 : 0
• Ecotoxicity Fresh Water Ctue Operational Energy Use B6 : 0
• Ecotoxicity Fresh Water Ctue End Of Life C1 C4 : 44.235093797937616
• Ecotoxicity Fresh Water Ctue Benefits Loads Beyond System Boundaries D : -73.38921250916013
• Emission Of Fine Particles Incidence Of Diseases Total Life Cycle : 0.00000417185973608558
• Emission Of Fine Particles Incidence Of Diseases Manufacturing A1 A3 : 0.00000396760865762256
• Emission Of Fine Particles Incidence Of Diseases Distribution A4 : 0.00000007978122027274
• Emission Of Fine Particles Incidence Of Diseases Installation A5 : 0.00000000695107858315
• Emission Of Fine Particles Incidence Of Diseases Maintenance B2 : 0
• Emission Of Fine Particles Incidence Of Diseases Repair B3 : 0
• Emission Of Fine Particles Incidence Of Diseases Replacement B4 : 0
• Emission Of Fine Particles Incidence Of Diseases Operational Energy Use B6 : 0
• Emission Of Fine Particles Incidence Of Diseases End Of Life C1 C4 : 0.00000011751877960713
• Emission Of Fine Particles Incidence Of Diseases Benefits Loads Beyond System Boundaries D : -0.00000317662107178088
• Exported Energy Mj By Energy Vector Total Life Cycle : 0.038933996047623015
• Exported Energy Mj By Energy Vector Manufacturing A1 A3 : 0.00300675781138216
• Exported Energy Mj By Energy Vector Distribution A4 : 0
• Exported Energy Mj By Energy Vector Installation A5 : 0.01615483329743197
• Exported Energy Mj By Energy Vector Maintenance B2 : 0
• Exported Energy Mj By Energy Vector Repair B3 : 0
• Exported Energy Mj By Energy Vector Replacement B4 : 0
• Exported Energy Mj By Energy Vector Operational Energy Use B6 : 0
• Exported Energy Mj By Energy Vector End Of Life C1 C4 : 0.019772404938808885
• Exported Energy Mj By Energy Vector Benefits Loads Beyond System Boundaries D : 0
• Freshwater Eutrophication Kg P Eq Total Life Cycle : 0.00012404429966643836
• Freshwater Eutrophication Kg P Eq Manufacturing A1 A3 : 0.00010483668716433869
• Freshwater Eutrophication Kg P Eq Distribution A4 : 0.00000082224560486645
• Freshwater Eutrophication Kg P Eq Installation A5 : 0.00000906021092660742
• Freshwater Eutrophication Kg P Eq Maintenance B2 : 0
• Freshwater Eutrophication Kg P Eq Repair B3 : 0
• Freshwater Eutrophication Kg P Eq Replacement B4 : 0
• Freshwater Eutrophication Kg P Eq Operational Energy Use B6 : 0
• Freshwater Eutrophication Kg P Eq End Of Life C1 C4 : 0.00000932515597062578
• Freshwater Eutrophication Kg P Eq Benefits Loads Beyond System Boundaries D : -0.00004928671351541064
• Hazardous Waste Disposed Of Kg Total Life Cycle : 147.22021802699936
• Hazardous Waste Disposed Of Kg Manufacturing A1 A3 : 146.77292123868654
• Hazardous Waste Disposed Of Kg Distribution A4 : 0.005817823579438674
• Hazardous Waste Disposed Of Kg Installation A5 : 0.009859280981940423
• Hazardous Waste Disposed Of Kg Maintenance B2 : 0
• Hazardous Waste Disposed Of Kg Repair B3 : 0
• Hazardous Waste Disposed Of Kg Replacement B4 : 0
• Hazardous Waste Disposed Of Kg Operational Energy Use B6 : 0
• Hazardous Waste Disposed Of Kg End Of Life C1 C4 : 0.431619683751447
• Hazardous Waste Disposed Of Kg Benefits Loads Beyond System Boundaries D : -140.70775419453608
• Human Toxicity Carcinogenic Effects Ctuh Total Life Cycle : 0.00000087243814494637
• Human Toxicity Carcinogenic Effects Ctuh Manufacturing A1 A3 : 0.0000008100918202003
• Human Toxicity Carcinogenic Effects Ctuh Distribution A4 : 0.00000000010342471053
• Human Toxicity Carcinogenic Effects Ctuh Installation A5 : 0.00000004469463111033
• Human Toxicity Carcinogenic Effects Ctuh Maintenance B2 : 0
• Human Toxicity Carcinogenic Effects Ctuh Repair B3 : 0
• Human Toxicity Carcinogenic Effects Ctuh Replacement B4 : 0
• Human Toxicity Carcinogenic Effects Ctuh Operational Energy Use B6 : 0
• Human Toxicity Carcinogenic Effects Ctuh End Of Life C1 C4 : 0.00000001754826892521
• Human Toxicity Carcinogenic Effects Ctuh Benefits Loads Beyond System Boundaries D : -0.00001613043957536147
• Human Toxicity Non Carcinogenic Effects Ctuh Total Life Cycle : 0.00000086675882950714
• Human Toxicity Non Carcinogenic Effects Ctuh Manufacturing A1 A3 : 0.00000083228502518688
• Human Toxicity Non Carcinogenic Effects Ctuh Distribution A4 : 0.00000001247920494086
• Human Toxicity Non Carcinogenic Effects Ctuh Installation A5 : 0.00000000116578516272
• Human Toxicity Non Carcinogenic Effects Ctuh Maintenance B2 : 0
• Human Toxicity Non Carcinogenic Effects Ctuh Repair B3 : 0
• Human Toxicity Non Carcinogenic Effects Ctuh Replacement B4 : 0
• Human Toxicity Non Carcinogenic Effects Ctuh Operational Energy Use B6 : 0
• Human Toxicity Non Carcinogenic Effects Ctuh End Of Life C1 C4 : 0.00000002082881421668
• Human Toxicity Non Carcinogenic Effects Ctuh Benefits Loads Beyond System Boundaries D : -0.00000077496528020245
• Impacts Related To Land Use Soil Quality Total Life Cycle : 2.8440920661518434
• Impacts Related To Land Use Soil Quality Manufacturing A1 A3 : 2.802316045086822
• Impacts Related To Land Use Soil Quality Distribution A4 : 0
• Impacts Related To Land Use Soil Quality Installation A5 : 0.0010810802022578724
• Impacts Related To Land Use Soil Quality Maintenance B2 : 0
• Impacts Related To Land Use Soil Quality Repair B3 : 0
• Impacts Related To Land Use Soil Quality Replacement B4 : 0
• Impacts Related To Land Use Soil Quality Operational Energy Use B6 : 0
• Impacts Related To Land Use Soil Quality End Of Life C1 C4 : 0.04069494086276369
• Impacts Related To Land Use Soil Quality Benefits Loads Beyond System Boundaries D : 0
• Ionizing Radiation Human Health Kbq Of U235 Equiv Total Life Cycle : 22.36654595249877
• Ionizing Radiation Human Health Kbq Of U235 Equiv Manufacturing A1 A3 : 21.683921344864967
• Ionizing Radiation Human Health Kbq Of U235 Equiv Distribution A4 : 0.015568674236922514
• Ionizing Radiation Human Health Kbq Of U235 Equiv Installation A5 : 0.060422915977989135
• Ionizing Radiation Human Health Kbq Of U235 Equiv Maintenance B2 : 0
• Ionizing Radiation Human Health Kbq Of U235 Equiv Repair B3 : 0
• Ionizing Radiation Human Health Kbq Of U235 Equiv Replacement B4 : 0
• Ionizing Radiation Human Health Kbq Of U235 Equiv Operational Energy Use B6 : 0
• Ionizing Radiation Human Health Kbq Of U235 Equiv End Of Life C1 C4 : 0.6066330174188923
• Ionizing Radiation Human Health Kbq Of U235 Equiv Benefits Loads Beyond System Boundaries D : -5.572522904808673
• Marine Aquatic Eutrophication Kg Of N Equiv Total Life Cycle : 0.042381321766745035
• Marine Aquatic Eutrophication Kg Of N Equiv Manufacturing A1 A3 : 0.02494787409384137
• Marine Aquatic Eutrophication Kg Of N Equiv Distribution A4 : 0.013185399019506359
• Marine Aquatic Eutrophication Kg Of N Equiv Installation A5 : 0.0005033826941268857
• Marine Aquatic Eutrophication Kg Of N Equiv Maintenance B2 : 0
• Marine Aquatic Eutrophication Kg Of N Equiv Repair B3 : 0
• Marine Aquatic Eutrophication Kg Of N Equiv Replacement B4 : 0
• Marine Aquatic Eutrophication Kg Of N Equiv Operational Energy Use B6 : 0
• Marine Aquatic Eutrophication Kg Of N Equiv End Of Life C1 C4 : 0.0037446659592704243
• Marine Aquatic Eutrophication Kg Of N Equiv Benefits Loads Beyond System Boundaries D : -0.008860170086015468
• Materials For Energy Recovery Kg Total Life Cycle : 0
• Materials For Energy Recovery Kg Manufacturing A1 A3 : 0
• Materials For Energy Recovery Kg Distribution A4 : 0
• Materials For Energy Recovery Kg Installation A5 : 0
• Materials For Energy Recovery Kg Maintenance B2 : 0
• Materials For Energy Recovery Kg Repair B3 : 0
• Materials For Energy Recovery Kg Replacement B4 : 0
• Materials For Energy Recovery Kg Operational Energy Use B6 : 0
• Materials For Energy Recovery Kg End Of Life C1 C4 : 0
• Materials For Energy Recovery Kg Benefits Loads Beyond System Boundaries D : 0
• Materials For Recycling Kg Total Life Cycle : 2.381664829332892
• Materials For Recycling Kg Manufacturing A1 A3 : 0.2978332283279863
• Materials For Recycling Kg Distribution A4 : 0
• Materials For Recycling Kg Installation A5 : 0
• Materials For Recycling Kg Maintenance B2 : 0
• Materials For Recycling Kg Repair B3 : 0
• Materials For Recycling Kg Replacement B4 : 0
• Materials For Recycling Kg Operational Energy Use B6 : 0
• Materials For Recycling Kg End Of Life C1 C4 : 2.083831601004906
• Materials For Recycling Kg Benefits Loads Beyond System Boundaries D : 0
• Net Use Of Fresh Water M3 Total Life Cycle : 0.41143662312556595
• Net Use Of Fresh Water M3 Manufacturing A1 A3 : 0.33698272838045656
• Net Use Of Fresh Water M3 Distribution A4 : 0.008294718190197597
• Net Use Of Fresh Water M3 Installation A5 : 0.0007109446522016382
• Net Use Of Fresh Water M3 Maintenance B2 : 0
• Net Use Of Fresh Water M3 Repair B3 : 0
• Net Use Of Fresh Water M3 Replacement B4 : 0
• Net Use Of Fresh Water M3 Operational Energy Use B6 : 0
• Net Use Of Fresh Water M3 End Of Life C1 C4 : 0.06544823190271012
• Net Use Of Fresh Water M3 Benefits Loads Beyond System Boundaries D : -0.13171751153574704
• Non Hazardous Waste Disposed Of Kg Total Life Cycle : 32.66246613223124
• Non Hazardous Waste Disposed Of Kg Manufacturing A1 A3 : 29.879026439853146
• Non Hazardous Waste Disposed Of Kg Distribution A4 : 0.0071471113000573586
• Non Hazardous Waste Disposed Of Kg Installation A5 : 0.16921649007281986
• Non Hazardous Waste Disposed Of Kg Maintenance B2 : 0
• Non Hazardous Waste Disposed Of Kg Repair B3 : 0
• Non Hazardous Waste Disposed Of Kg Replacement B4 : 0
• Non Hazardous Waste Disposed Of Kg Operational Energy Use B6 : 0
• Non Hazardous Waste Disposed Of Kg End Of Life C1 C4 : 2.607076091005213
• Non Hazardous Waste Disposed Of Kg Benefits Loads Beyond System Boundaries D : -19.915942220574586
• Ozone Depletion Kg Equivalent Cfc 11 Total Life Cycle : 0.00000951158499176276
• Ozone Depletion Kg Equivalent Cfc 11 Manufacturing A1 A3 : 0.00000318272590509349
• Ozone Depletion Kg Equivalent Cfc 11 Distribution A4 : 0.00000619669464470811
• Ozone Depletion Kg Equivalent Cfc 11 Installation A5 : 0.00000000512280868352
• Ozone Depletion Kg Equivalent Cfc 11 Maintenance B2 : 0
• Ozone Depletion Kg Equivalent Cfc 11 Repair B3 : 0
• Ozone Depletion Kg Equivalent Cfc 11 Replacement B4 : 0
• Ozone Depletion Kg Equivalent Cfc 11 Operational Energy Use B6 : 0
• Ozone Depletion Kg Equivalent Cfc 11 End Of Life C1 C4 : 0.00000012704163327763
• Ozone Depletion Kg Equivalent Cfc 11 Benefits Loads Beyond System Boundaries D : -0.00000212675548286934
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Total Life Cycle : 0.1454563118810957
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Manufacturing A1 A3 : 0.08550269704322648
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Distribution A4 : 0.04767955539076962
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Installation A5 : 0.0008026873953996981
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Maintenance B2 : 0
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Repair B3 : 0
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Replacement B4 : 0
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Operational Energy Use B6 : 0
• Photochemical Ozone Formation Kg Of Nmvoc Equiv End Of Life C1 C4 : 0.011471372051699869
• Photochemical Ozone Formation Kg Of Nmvoc Equiv Benefits Loads Beyond System Boundaries D : -0.03466296977235655
• Radioactive Waste Disposed Of Kg Total Life Cycle : 0.023000352378681532
• Radioactive Waste Disposed Of Kg Manufacturing A1 A3 : 0.021433915095091394
• Radioactive Waste Disposed Of Kg Distribution A4 : 0.001396116985454834
• Radioactive Waste Disposed Of Kg Installation A5 : 0.00002091445459666688
• Radioactive Waste Disposed Of Kg Maintenance B2 : 0
• Radioactive Waste Disposed Of Kg Repair B3 : 0
• Radioactive Waste Disposed Of Kg Replacement B4 : 0
• Radioactive Waste Disposed Of Kg Operational Energy Use B6 : 0
• Radioactive Waste Disposed Of Kg End Of Life C1 C4 : 0.00014940584353863765
• Radioactive Waste Disposed Of Kg Benefits Loads Beyond System Boundaries D : -0.01451226815397606
• Terrestrial Eutrophication Mole Of N Equiv Total Life Cycle : 0.45794816026622737
• Terrestrial Eutrophication Mole Of N Equiv Manufacturing A1 A3 : 0.26854277766369034
• Terrestrial Eutrophication Mole Of N Equiv Distribution A4 : 0.14302232653702207
• Terrestrial Eutrophication Mole Of N Equiv Installation A5 : 0.003501701753623289
• Terrestrial Eutrophication Mole Of N Equiv Maintenance B2 : 0
• Terrestrial Eutrophication Mole Of N Equiv Repair B3 : 0
• Terrestrial Eutrophication Mole Of N Equiv Replacement B4 : 0
• Terrestrial Eutrophication Mole Of N Equiv Operational Energy Use B6 : 0
• Terrestrial Eutrophication Mole Of N Equiv End Of Life C1 C4 : 0.04288135431189168
• Terrestrial Eutrophication Mole Of N Equiv Benefits Loads Beyond System Boundaries D : -0.09771430151263488
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 33.99236550055367
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 33.99236550055367
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Maintenance B2 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Repair B3 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Replacement B4 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Benefits Loads Beyond System Boundaries D : 0
• Total Use Of Primary Energy During The Life Cycle Mj Total Life Cycle : 640.3746673701062
• Total Use Of Primary Energy During The Life Cycle Mj Manufacturing A1 A3 : 498.9953434766642
• Total Use Of Primary Energy During The Life Cycle Mj Distribution A4 : 87.37324738999733
• Total Use Of Primary Energy During The Life Cycle Mj Installation A5 : 4.431608868946819
• Total Use Of Primary Energy During The Life Cycle Mj Maintenance B2 : 0
• Total Use Of Primary Energy During The Life Cycle Mj Repair B3 : 0
• Total Use Of Primary Energy During The Life Cycle Mj Replacement B4 : 0
• Total Use Of Primary Energy During The Life Cycle Mj Operational Energy Use B6 : 0
• Total Use Of Primary Energy During The Life Cycle Mj End Of Life C1 C4 : 49.57446763449783
• Total Use Of Primary Energy During The Life Cycle Mj Benefits Loads Beyond System Boundaries D : -255.63560496952928
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 29.52463510242916
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 26.48746262038221
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0.0005712276935762004
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.5138277193405174
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Maintenance B2 : 0
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Repair B3 : 0
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Replacement B4 : 0
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 2.522773535012852
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Benefits Loads Beyond System Boundaries D : -12.023616332039538
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 33.99236550055367
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 33.99236550055367
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Maintenance B2 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Repair B3 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Replacement B4 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Benefits Loads Beyond System Boundaries D : 0
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 576.8576667671231
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 438.51551535572804
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 87.37267616230378
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 3.9177811496063017
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Maintenance B2 : 0
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Repair B3 : 0
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Replacement B4 : 0
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 47.05169409948498
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Benefits Loads Beyond System Boundaries D : -243.61198863748976
• Use Of Non Renewable Secondary Fuels Mj Total Life Cycle : 0
• Use Of Non Renewable Secondary Fuels Mj Manufacturing A1 A3 : 0
• Use Of Non Renewable Secondary Fuels Mj Distribution A4 : 0
• Use Of Non Renewable Secondary Fuels Mj Installation A5 : 0
• Use Of Non Renewable Secondary Fuels Mj Maintenance B2 : 0
• Use Of Non Renewable Secondary Fuels Mj Repair B3 : 0
• Use Of Non Renewable Secondary Fuels Mj Replacement B4 : 0
• Use Of Non Renewable Secondary Fuels Mj Operational Energy Use B6 : 0
• Use Of Non Renewable Secondary Fuels Mj End Of Life C1 C4 : 0
• Use Of Non Renewable Secondary Fuels Mj Benefits Loads Beyond System Boundaries D : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 7.80797552414661
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 7.80797552414661
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Maintenance B2 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Repair B3 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Replacement B4 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Benefits Loads Beyond System Boundaries D : -5.466086265657367
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 21.716659578282545
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 18.679487096235597
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0.0005712276935762004
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.5138277193405174
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Maintenance B2 : 0
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Repair B3 : 0
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Replacement B4 : 0
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 2.522773535012852
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Benefits Loads Beyond System Boundaries D : -6.557530066382168
• Use Of Renewable Secondary Fuels Mj Total Life Cycle : 0
• Use Of Renewable Secondary Fuels Mj Manufacturing A1 A3 : 0
• Use Of Renewable Secondary Fuels Mj Distribution A4 : 0
• Use Of Renewable Secondary Fuels Mj Installation A5 : 0
• Use Of Renewable Secondary Fuels Mj Maintenance B2 : 0
• Use Of Renewable Secondary Fuels Mj Repair B3 : 0
• Use Of Renewable Secondary Fuels Mj Replacement B4 : 0
• Use Of Renewable Secondary Fuels Mj Operational Energy Use B6 : 0
• Use Of Renewable Secondary Fuels Mj End Of Life C1 C4 : 0
• Use Of Renewable Secondary Fuels Mj Benefits Loads Beyond System Boundaries D : 0
• Use Of Secondary Materials Kg Total Life Cycle : 0
• Use Of Secondary Materials Kg Manufacturing A1 A3 : 0
• Use Of Secondary Materials Kg Distribution A4 : 0
• Use Of Secondary Materials Kg Installation A5 : 0
• Use Of Secondary Materials Kg Maintenance B2 : 0
• Use Of Secondary Materials Kg Repair B3 : 0
• Use Of Secondary Materials Kg Replacement B4 : 0
• Use Of Secondary Materials Kg Operational Energy Use B6 : 0
• Use Of Secondary Materials Kg End Of Life C1 C4 : 0
• Use Of Secondary Materials Kg Benefits Loads Beyond System Boundaries D : 0
• Water Use M3 Eq Total Life Cycle : 16.03785643348486
• Water Use M3 Eq Manufacturing A1 A3 : 14.4572166677935
• Water Use M3 Eq Distribution A4 : 0.35625814626898683
• Water Use M3 Eq Installation A5 : 0.030526102955284528
• Water Use M3 Eq Maintenance B2 : 0
• Water Use M3 Eq Repair B3 : 0
• Water Use M3 Eq Replacement B4 : 0
• Water Use M3 Eq Operational Energy Use B6 : 0
• Water Use M3 Eq End Of Life C1 C4 : 1.1938555164670872
• Water Use M3 Eq Benefits Loads Beyond System Boundaries D : -5.657041013681866
• Air Pollution M3 Total Life Cycle : 0
• Air Pollution M3 Manufacturing A1 A3 : 0
• Air Pollution M3 Distribution A4 : 0
• Air Pollution M3 Installation A5 : 0
• Air Pollution M3 Maintenance B2 : 0
• Air Pollution M3 Repair B3 : 0
• Air Pollution M3 Replacement B4 : 0
• Air Pollution M3 Operational Energy Use B6 : 0
• Air Pollution M3 End Of Life C1 C4 : 0
• Air Pollution M3 Benefits Loads Beyond System Boundaries D : 0
• Water Pollution M3 Total Life Cycle : 0
• Water Pollution M3 Manufacturing A1 A3 : 0
• Water Pollution M3 Distribution A4 : 0
• Water Pollution M3 Installation A5 : 0
• Water Pollution M3 Maintenance B2 : 0
• Water Pollution M3 Repair B3 : 0
• Water Pollution M3 Replacement B4 : 0
• Water Pollution M3 Operational Energy Use B6 : 0
• Water Pollution M3 End Of Life C1 C4 : 0
• Water Pollution M3 Benefits Loads Beyond System Boundaries D : 0
• General Attributes
• Product Or Component Type : fan
• Environment Attributes
• ROHS Exemption Information : Yes
• China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=10178375&lang=en-us
• Take Back : No
• China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
• Mercury Free : Yes
• Carbon Footprint : 35.8193796005866
• Circularity Profile : ENVEOLI1107017EN
• Environmental Disclosure : ENVPEP110717EN
• EU ROHS Directive : Compliant with Exemptions
• IP Degree Of Protection : IP54
• Packaging Made With Recycled Cardboard : No
• Packaging Without Single Use Plastic : No
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Pep Code : ENVPEP110717EN
• Pep Verification Date : 2025-08-05
• PCR Version : PEP-PCR-ed4-2021 09 06
• PSR Version : PSR-0008-ed3-EN-2023 10 19
• Type Of Verification For The Pep : Independent external review
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Country of Origin : France
• Height : 13.23 in
• Width : 12.44 in
• Depth : 0 in
