9422ATCF disconnect switches are designed for control panel installations. These disconnect switch is fully compatible with 9422A handle operators and 9423 door closing mechanisms. This replacement fuse clip kit is for 9422TCF30, 9422TCN30, 9422TCF33 and 9422TDN60 flange mounted variable depth discoonect switches. This fuse clip kit will accept Class H, J, K or R fuses only. It has a ratings of 30A and 60A up to 600 V depending on which disconnect switch it is used with. Disconnect switch lugs are rated for 14 to 2 AWG with copper wire and 10 to 2 with aluminum wire. Disconnect switch is UL Component Recognized and CSA certified

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Complementary Attributes
• Maximum Horse Power Rating : 7.5 hp 200 V AC, 7.5 hp 230 V AC, 15 hp 460 V AC, 20 hp 575 V AC, 5 hp 250 V DC
• Line Rated Current : 30 A
• Important Information Attributes
• Persona Type Ids : EU, LC, OM8, PB
• Persona Type Names : End User, Contractor, OEM - Control Panelbuilder, Panel Builder
• Market Segmentation Id : COMMERCIAL, INDUSTRIAL
• Market Segmentation : Commercial, Industrial
• Associated Fuse Rating : 60 A 250 V, 30 A 600 V
• Fuse Type : R, K, H, J
• Certificate Agency : CSA, UL Recognized
• Local Data Status : Publishable
• Local Publishable Date : 2025-11-13
• Return Indicator : N
• Stocking Flag : Y
• Stock Policy : 2
• Serviceability : No
• Traceability : No
• Weee Scope : In
• Weee Product Category : 5
• Scope Perimeter : At least in Europe
• Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
• Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
• Rohs Eur In Scope : Yes
• Rohs Eur Status : Compliant
• Rohs Eur Conformity Date : 1920
• Rohs Eur Full Compliance Status : Compliant
• China Rohs In Scope : Yes
• China Rohs Label : 1
• With Recycled Cardboard : Yes
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Tier Id : 2
• Tier : 2
• Function Option Id : STANDARD
• Function Option : Standard
• Product Kit Identifier : N
• Disconnector Device Type : fusible disconnect switch
• Energy Efficiency Optimized : False
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : Disconnect Switch
• Provided Equipment : ordered separately
• Range Of Product : 9422T
• Returnability : No
• Sustainable Packaging : No
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Warranty In Months : 18
• Offer Owner Code : 190788
• Pn : 1
• Environment Attributes Main
• Take Back : No
• Reach Free Shvc : Yes
• Recycled Metal Content At Cr Level : 0 %
• China Rohs Regulation : X
• Toxic Heavy Metal Free : Yes
• Mercury Free : Yes
• Eu Rohs Directive : Compliant
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : No
• Reach Free Of Svhc : Yes
• Reach Regulation : Free of Substances of Very High Concern above the threshold
• General Attributes
• Product Or Component Type : Disconnect Switch
• Provided Equipment : ordered separately
• Range Of Product : 9422T
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Country of Origin : Mexico
