Auxiliary contact block,TeSys Control,1 NO + 1 NO,for V02-V6

AUXILIARY CONTACT

SQDVZ20 VZ20 3389110551976
46.21 / EA
http://schema.org/OutOfStock
Mayer-DDS-Auxiliary contact block,TeSys Control,1 NO + 1 NO,for V02-V6-1
  • Country of Origin: Czechia
  • Depth: 48.5 mm
  • Height: 65 mm
  • Net Weight: 0.05 kg
  • Warranty Length: 18 mth
  • Weight: 0.05 kg
  • Width: 20 mm
VZ20 is an add-on auxiliary contact module for TeSys Vario switch-disconnectors from Schneider Electric. To be used with V02 to V6 switch bodies, mounted on one side of the switch body. It includes 2NO late make contacts rated for AC operation until 690V and DC operation until 250V. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC). Multi standards certified (IEC, UL, CSA, CCC, EAC).
QTY
  • Product Description
  • Specifications
VZ20 is an add-on auxiliary contact module for TeSys Vario switch-disconnectors from Schneider Electric. To be used with V02 to V6 switch bodies, mounted on one side of the switch body. It includes 2NO late make contacts rated for AC operation until 690V and DC operation until 250V. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC). Multi standards certified (IEC, UL, CSA, CCC, EAC).
  • Environment
    • Product Certifications : GL || UL || CSA || UKCA
    • Ambient Air Temperature For Operation : -20-50 °C
    • Standards : IEC 60947-5
    • Ip Degree Of Protection : IP20 conforming to IEC 60529
    • Protective Treatment : TC
    • Fire Resistance : 960 °C IEC 60695-2-1
  • Contractual warranty
    • Warranty : 18 months
  • Environmental data
    • Packaging Made With Recycled Cardboard : Yes
    • Environmental Disclosure : ENVPEP2211001
    • Halogen Content Performance : Halogen free product
    • Packaging Without Single Use Plastic : No
    • Scip Number : 65661eb0-9ea7-4d52-b0a4-16b981f28f63
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • Circularity Profile : N/A
    • Take-Back : No
    • Pvc Free : Yes
    • Carbon Footprint (Kg Co2 Eq, Total Life Cycle) : 0.5107007432432431
  • Complementary
    • [Ue] Rated Operational Voltage : 690 V AC 50/60 Hz
    • Height : 65 mm
    • [Ith] Conventional Free Air Thermal Current : 12 A
    • [Ithe] Conventional Enclosed Thermal Current : 10 A
    • Net Weight : 0.05 kg
    • [Uimp] Rated Impulse Withstand Voltage : 8 kV
    • Connections - Terminals : screw clamp terminals 2 0.75-1.5 mm² flexible - with cable end || screw clamp terminals 2 1-2.5 mm² solid
    • Electrical Durability : 30000 cycles DC-11 || 100000 cycles AC-15
    • Mechanical Durability : 100000 cycles
    • Width : 20 mm
    • Tightening Torque : 0.7-0.7 N.m screw clamp terminals
    • Depth : 48.5 mm
  • Specifications
    • Country of Origin : Czechia
    • Width : 20 mm
    • Height : 65 mm
    • Weight : 0.05 kg
    • Network Frequency : 50/60 Hz
    • Network Type : DC || AC
    • Product Or Component Type : auxiliary contact block
    • Performance Level : high performance
    • Range : TeSys
    • Mounting Location : left || right
    • Contacts Type And Composition : 1 NO + 1 NO
    • Product Compatibility : V3 || V01 || V2 || V0 || V6 || V4 || V1 || V5 || V02
    • Device Short Name : VZ
