The Square D™ by Schneider Electric brand Heavy Duty Safety Switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. F Series safety switches provide significantly higher levels of mechanical endurance than NEMA KS-1 or UL98 standards require. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock and a color-coded indicator handle. This Square D heavy duty safety switch grounding bar comes in 30A & 60A. This Solid Insulated Groundable Neutral Assembly has a currrent rating of 400A/600A and has a terminal service ground. This neutral is for series E 4 and 5 safety switchs. This accessory has a UL listed & CSA certifications. This safety switch solid neutral assembly are for safety switchwith aUL listed certification and a switch function of

• CAD
• https://download.schneider-electric.com/files?p_Doc_Ref=1930&p_File_name=1930.dwg
• https://download.schneider-electric.com/files?p_Doc_Ref=1930&p_File_name=1930.dxf
• https://download.schneider-electric.com/files?p_Doc_Ref=3452&p_File_name=3452.dwg
• https://download.schneider-electric.com/files?p_Doc_Ref=3452&p_File_name=3452.dxf
• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Electrical Connection
• terminal, service ground
• Market Segmentation
• Commercial
• Industrial
• Persona Type Names
• Contractor
• OEM - Control Panelbuilder
• Panel Builder
• Persona Type Ids
• LC
• OM8
• PB
• Tightening Torque
• 340-340 lbf.in (AWG 1...750 kcmil)
• 250-250 lbf.in (AWG 4...300 kcmil)
• AWG Gauge
• AWG 1...750 kcmil 4 aluminium/copper
• AWG 4...300 kcmil 1 aluminium/copper
• Market Segmentation Id
• COMMERCIAL
• INDUSTRIAL
• Product Destination
• safety switch series E 4 and 5 400-400 A
• safety switch series E 4 and 5 600-600 A

• Important Information Attributes
• B2B Bullet Point 1 : Fusible and non-fusible options
• B2B Bullet Point 2 : 30A to 1200A rated amps
• B2B Bullet Point 3 : Type 1/3R/12/4X enclosures
• B2B Bullet Point 4 : 500hp maximum
• B2B Bullet Point 5 : UL listed
• Local Data Status : Publishable
• Local Publishable Date : 2025-11-13
• Serviceability : No
• Traceability : No
• Field Service Division : PPIBS
• Legacy WEEE Scope : In
• WEEE Product Category : 4
• Scope Perimeter : Outside of Europe
• EOLI Availability Display : No need of specific recycling operations
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• ROHS EUR In Scope : Yes
• ROHS EUR Status : Compliant with Exemptions
• ROHS EUR Conformity Date : 1906
• ROHS EUR Full Compliance Status : Compliant with Exemptions
• ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
• China ROHS In Scope : Yes
• China ROHS Label : 7
• With Recycled Cardboard : Yes
• Without Single Use Plastic : Yes
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : Y
• WD Status : 1 - GSC certified
• Tier Id : 1
• Tier : 1
• Function Option Id : STANDARD
• Function Option : Standard
• Energy Efficiency Optimized : False
• Halogen Free Status : Halogen free plastic parts product
• Package Weight Lbs : 1.533 kg
• Product Availability : Stock - Normally stocked in distribution facility
• Product Or Component Type : safety switch solid neutral assembly
• Returnability : Yes
• Sustainable Packaging : Yes
• Relationship Type : Compatible relationship
• Nbr Of Units In Pkg : 1
• Warranty In Months : 18
• General Attributes
• Product Or Component Type : safety switch solid neutral assembly
• Environment Attributes
• ROHS Exemption Information : Yes
• China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=364877&lang=en-us
• Take Back : No
• Halogene Performance : Halogen free plastic parts product
• Recycled Metal Content At Cr Level : 0 %
• China ROHS Regulation : X
• Mercury Free : Yes
• EU ROHS Directive : Compliant with Exemptions
• Halogen Content Performance : Halogen free plastic parts product
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : Yes
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Country of Origin : United States
