Automatic switch, PowerPacT P, 1200A, 3 pole, 600VAC, 25kA, lugs, magnetic, black rotary handle

AUTOMATIC MOLDED CASE SWITCH 6

SQDPJL36000S12RE10 PJL36000S12RE10 785901899075
13142.90 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Automatic switch, PowerPacT P, 1200A, 3 pole, 600VAC, 25kA, lugs, magnetic, black rotary handle-1
  • Depth: 14.49 in
  • Warranty Length: 18 mth
PowerPacT P-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection possibilities as the P-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. The automatic switch can make and break its rated current. PowerPacT P-Frame switches are available in unit mount, I-Line, plug-in, or drawout constructions. This switch has lugs on both the line and load sides. This PowerPacT P, 1200A, 3 pole, automatic switch has a short circuit withstand current rating of 25kA at 600VAC. This unit includes a standard black handle. PowerPacT P automatic switches comply to UL, CSA, ANCE, and IEC standards.
QTY
  • Product Description
  • Features
  • Specifications
PowerPacT P-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection possibilities as the P-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. The automatic switch can make and break its rated current. PowerPacT P-Frame switches are available in unit mount, I-Line, plug-in, or drawout constructions. This switch has lugs on both the line and load sides. This PowerPacT P, 1200A, 3 pole, automatic switch has a short circuit withstand current rating of 25kA at 600VAC. This unit includes a standard black handle. PowerPacT P automatic switches comply to UL, CSA, ANCE, and IEC standards.
  • Features
    • To open and close a circuit under normal operating conditions
    • Can make and break its rated current
    • Factory set nonadjustable trip point to protect the molded case switch
    • A wide range of accessories, auxiliaries, and lug connections available
    • UL 489 Listed, CSA, ANCE, IEC certified
  • Prop 65
    • WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Conformance Attributes
    • Product Certifications : UL Listed, IEC, CSA
  • Complementary Attributes
    • Short Circuit Withstand : 65 kA 480 V UL 489, 25 kA 600 V UL 489, 100 kA 240 V UL 489
    • Line Rated Current : 1200 A
  • Important Information Attributes
    • Persona Type Ids : LC, OM, OM8, PB
    • Persona Type Names : Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
    • Market Segmentation Id : COMMERCIAL, INDUSTRIAL
    • Market Segmentation : Commercial, Industrial
    • Electrical Connection : lugs, line, lugs, load
    • Short Circuit Withstand : 65 kA 480 V UL 489, 25 kA 600 V UL 489, 100 kA 240 V UL 489
    • Carbon Footprint Of The Distribution Phase A4 : 4.194654907690849, 4 kg CO2 eq.
    • Carbon Footprint Of The End Of Life Phase C1 To C4 : 19 kg CO2 eq., 19.219047362819378
    • Carbon Footprint Of The Installation Phase A5 : 2.5241627657841312, 3 kg CO2 eq.
    • Carbon Footprint Of The Manufacturing Phase A1 To A3 : 108 kg CO2 eq., 108.38202238849306
    • Carbon Footprint Of The Use Phase B2 B3 B4 B6 : 1 135 kg CO2 eq., 1135.4719935073902
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-13
    • Device Type : LV equipment - LV switch - disconnector
    • Serviceability : No
    • Traceability : Yes
    • Field Service Division : PPIBS
    • Average Life Duration : 15 year(s)
    • Legacy WEEE Scope : In
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI2206033_V2
    • ROHS EUR In Scope : Yes
    • ROHS EUR Status : Compliant
    • ROHS EUR Full Compliance Status : Compliant
    • ROHS EUR Full Compliance Status Id : COMPLIANT
    • China ROHS In Scope : No
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • Function Option Id : STANDARD
    • Function Option : Standard
    • AWG Gauge : 4 x AWG 3/0...500 kcmil ( aluminium/copper )
    • Magnetic Tripping Current : 10000-10000 A
    • Mounting Mode : unit mount
    • Package Weight Lbs : 14.515 kg
    • Poles Description : 3P
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : automatic switch
    • Range Of Product : PowerPact P
    • Returnability : No
    • Sustainable Packaging : No
    • Terminal Identifier : AL1200P25K
    • Tightening Torque : 50-50 N.m 95-240 mm² (AWG 3/0...500 kcmil)
    • Total Lifecycle Carbon Footprint : 1 270 kg CO2 eq.
    • Trip Unit Technology : magnetic
    • Ue Rated Operational Voltage2 : 600 V AC
    • Accessory Separate Part Type2 : rotary handle
    • Medium Desc : Automatic switch, PowerPacT P, 1200A, 3 pole, 600VAC, 25kA, lugs, magnetic, black rotary handle
    • Stocking Flag : Y
    • Product Kit Identifier : N
    • Pep Code : ENVPEP2206033EN
    • Database Version : 2024-01
    • Pep Verification Date : 2025-06-25
    • Pcr Version : PEP-PCR-ed4-2021 09 06
    • Psr Version : PSR-0005-ed3.1-EN-2023 12 08
    • Type Of Verification For The Pep : Independent external review
    • Data Source : extrapolated product
    • Functional Unit Description : Protect the installation from overloads and short circuits in a circuit with rated voltage Ue, rated current In, with Np poles, a rated breaking capacity Icu, and, if applicable, the specific specifications, in the Industrial application area, according to the appropriate use scenario, and during the reference service life of the product of 20 years.
    • Functional Unit Unit : unit
    • Energy Model Manufacturing A1 A3 2 : Electricity Mix; Low voltage; 2020; United States, US
    • Energy Model Installation A5 2 : [A5]
    • Energy Model Use B6 2 : Electricity Mix; Low voltage; 2020; United States, US
    • Energy Model End Of Life C1 C4 2 : [C1 - C4]
    • Global Commercial Status : Commercialised
    • Accessory Separate Part Type3 : rotary handle
    • Ue Rated Operational Voltage5 : 600 V AC
  • Environment Attributes Main
    • Take Back : No, Nej
    • China ROHS Regulation : Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
    • EU ROHS Directive : Compliant , Compliant
    • ROHS Exemption Information : Yes
    • Recycled Metal Content At Cr Level : 0 %
    • Mercury Free : Yes
    • Carbon Footprint : 1269.7918809321775
    • Circularity Profile : ENVEOLI2206033_V2
    • Environmental Disclosure : ENVPEP2206033EN
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : No
    • Pep Code : ENVPEP2206033EN
    • Pep Verification Date : 2025-06-25
    • Pcr Version : PEP-PCR-ed4-2021 09 06
    • Psr Version : PSR-0005-ed3.1-EN-2023 12 08
    • Type Of Verification For The Pep : Independent external review
  • General Attributes
    • Product Or Component Type : automatic switch
    • Range Of Product : PowerPact P
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Depth : 14.49 in
