QO Load Centers offer premium features like QO breakers, ground arc fault interrupters and surge arresters. QO load centers are designed for residential and industrial use to protect electrical systems, equipment and people. Systems are single or three phase and have indoor and outdoor versions. QO Load Centers enable the use of a full complement of accessories. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This 2 pole mounting base is for use in a 125A single phase main lug load center. QO mounting base has a 10 kA breaking capacity. For use in NEMA 1 indoor load centers. Mounting base will accept a wire range of 14 AWG to 4 AWG copper or 12 AWG to 2 AWG aluminum wire. Base is UL Listed.

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Conformance Attributes
• Product Certifications : UL Listed
• Complementary Attributes
• Line Rated Current : 125 A
• Important Information Attributes
• Persona Type Ids : EU, LC, OM
• Persona Type Names : End User, Contractor, Original Equipment Manufacturer
• Awg Gauge : AWG 14...AWG 4 copper, AWG 12...AWG 2 aluminium
• Local Data Status : Publishable
• Local Publishable Date : 2025-11-13
• Global Commercial Status : Commercialised
• Return Indicator : N
• Stocking Flag : Y
• Stock Policy : 2
• H And D Domain : Safety
• H And D Subrange : RESI
• H And D Enrichment Assignment : yes
• H And D Enrichment Function : ACCESSORIES
• H And D Enrichment Class 3 : Enclosures
• H And D Enrichment Class 4 : Enclosure accessory
• Legacy Weee Scope : In
• Weee Product Category : 5
• Scope Perimeter : Outside of Europe
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• Rohs Eur In Scope : Yes
• Rohs Eur Status : Compliant By Exemption
• Rohs Eur Conformity Date : 1952
• Rohs Eur Full Compliance Status : Compliant By Exemption
• China Rohs In Scope : No
• With Recycled Cardboard : No
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Tier Id : 3
• Tier : 3
• Function Option Id : STANDARD
• Function Option : Standard
• Market Segmentation Id : RESIDENTIAL
• Market Segmentation : Residential
• Product Kit Identifier : N
• Energy Efficiency Optimized : False
• Load Center Type : main lugs
• Number Of Circuits : 2
• Number Of Spaces : 2
• Phase : 1 phase 2 wires
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : mounting base
• Range Of Product : QO
• Returnability : No
• Short Circuit Current : 10 kA
• Sustainable Packaging : No
• Tightening Torque : main lugs 50 lb.in, AWG 3...AWG 2, aluminium/copper
• Warranty In Months : 18
• Offer Owner Code : 190788
• Height Nominal : 107 mm
• Width Nominal : 64 mm
• Environment Attributes Main
• China Rohs Regulation : Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
• Take Back : Nej
• Recycled Metal Content At Cr Level : 0 %
• Mercury Free : Yes
• Eu Rohs Directive : Compliant By Exemption
• Nema Degree Of Protection : NEMA 1 indoor enclosure
• Packaging Made With Recycled Cardboard : No
• Packaging Without Single Use Plastic : No
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• General Attributes
• Phase : 1 phase 2 wires
• Product Or Component Type : mounting base
• Range Of Product : QO
• Specifications
• Depth : 34 mm
