QO Load Centers offer premium features by allowing QO breakers, ground fault interrupters, arc fault interrupters, and surge arresters to be installed inside. QO Load Centers are designed for residential and industrial use to protect electrical systems,

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Ue Rated Operational Voltage
• 120/240 V AC
• Phase
• 1 phase 3 wires
• Material
• tin plated copper: busbar
• Nema Degree Of Protection
• NEMA 1 indoor enclosure
• Accessories
• PK4DTIM4LA
• PK4MB2LA
• QOSAMK
• Tightening Torque
• main lugs 50 lb.in, AWG 6...AWG 2/0, aluminium/copper
• Cover 20 lb.in
• AWG Gauge
• AWG 6...AWG 2/0 aluminium/copper
• Ambient Air Temperature For Operation
• -5 °C
• 40 °C
• Surface Finish
• baked enamel Gray

• Conformance Attributes
• Product Certifications : UL Listed
• Complementary Attributes
• Line Rated Current : 125 A
• Important Information Attributes
• Country Id : US
• Local Data Status : Publishable
• Local Publishable Date : 2025-07-24
• Legacy WEEE Scope : In
• WEEE Product Category : 5
• Scope Perimeter : At least in Europe
• ROHS Eur In Scope : Yes
• ROHS Eur Status : Compliant
• ROHS Eur Conformity Date : 1906
• ROHS Eur Full Compliance Status : Compliant
• ROHS Eur Full Compliance Status Id : COMPLIANT
• China ROHS In Scope : No
• China ROHS Label : 1
• Return Indicator : N
• WD Status : A - SELECTED - PCE ONLY (Migration)
• H And D Domain : Safety
• H And D Enrichment Assignment : no
• H And D Enrichment Function : ENCLOSURES
• Box Number : 7
• Cover Type : order separately
• Device Composition : grounding bar included (not installed)
• Electrical Connection : lugs
• Enclosure Material : welded sheet steel
• Load Center Type : Convertible Mains (lugs)
• Number Of Circuits : 24
• Number Of Spaces : 24
• Number Of Tandem Circuit Breakers : 0
• Package Weight Lbs : 5.489 kg
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : Load Center
• Range Of Product : QO
• Returnability : No
• Short Circuit Current : 65 kA
• Sustainable Packaging : No
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Relationshiptype : Compatible relationship
• General Attributes
• Product Or Component Type : Load Center
• Range Of Product : QO
• Environment Attributes
• ROHS Exemption Information : Yes
• China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=360123&lang=en-us
• Reach Free Shvc : Yes
• China ROHS Regulation : Pro-active China RoHS declaration (out of China RoHS legal scope)
• Toxic Heavy Metal Free : Yes
• Mercury Free : Yes
• Eu Rohs Directive : Compliant
• Reach Free Of Svhc : Yes
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Height : 20.91 in
• Width : 14.25 in
