Load center interior, QO, mounting base, 1 phase, 2 spaces, 70A main lugs, OEM

OEM MOUNTING BASE 2SP 70A

SQDQON2L70 QON2L70 785901029410
28.05 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Load center interior, QO, mounting base, 1 phase, 2 spaces, 70A main lugs, OEM-2
  • Depth: 48 mm
  • Height: 69 mm
  • Net Weight: 0.700 kg
  • Number of Spaces: 2
  • Short Circuit Current Rating: 10 kA
  • Warranty Length: 18 mth
  • Weight: 0.700 kg
  • Width: 107 mm
QO Load Centers offer premium features like QO breakers, ground arc fault interrupters and surge arresters. QO load centers are designed for residential and industrial use to protect electrical systems, equipment and people. Systems are single or three phase and have indoor and outdoor versions. QO Load Centers enable the use of a full complement of accessories. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This QO OEM plug on mounting base is for 70A 240 VAC 1 phase 2 wire systems. This QO OEM mounting base has a 10 kA breaking capacity. This product is for 2 spaces. This mounting base will accept only QO plug on circuit breakers. The QON mounting base is UL component recognized.
QTY
  • Product Description
  • Features
  • Specifications
QO Load Centers offer premium features like QO breakers, ground arc fault interrupters and surge arresters. QO load centers are designed for residential and industrial use to protect electrical systems, equipment and people. Systems are single or three phase and have indoor and outdoor versions. QO Load Centers enable the use of a full complement of accessories. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This QO OEM plug on mounting base is for 70A 240 VAC 1 phase 2 wire systems. This QO OEM mounting base has a 10 kA breaking capacity. This product is for 2 spaces. This mounting base will accept only QO plug on circuit breakers. The QON mounting base is UL component recognized.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Specifications
    • Country of Origin : Mexico
    • Width : 107 mm
    • Height : 69 mm
    • Weight : 0.700 kg
    • Phase : 1 phase 2 wires
    • Range Of Product : QO
    • [Ue] Rated Operational Voltage : 120/240 V AC
    • Product Or Component Type : mounting base
    • Number Of Spaces : 2
    • Short-Circuit Current : 10 kA
    • Line Rated Current : 70 A
    • Load Center Type : main lugs
  • Complementary
    • Product Certifications : UL || CSA
    • Height : 69 mm
    • Net Weight : 0.700 kg
    • Awg Gauge : AWG 14...AWG 4 copper || AWG 12...AWG 3 aluminium
    • Width : 107 mm
    • Depth : 48 mm
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Packaging Made With Recycled Cardboard : No
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP2101006
    • Packaging Without Single Use Plastic : No
    • Toxic Heavy Metal Free : Yes
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Reach Free Of Svhc : Yes
    • China Rohs Regulation : Pro-active China RoHS declaration (out of China RoHS legal scope)
    • Circularity Profile : N/A
    • Take-Back : No
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
  • Contractual warranty
    • Warranty : 18 months
