SQUARE D

Load center accessory, QO/Homeline, ground bar kit, 23 terminals, with AWG 1-4/0 lug in aluminum or copper

GROUNDBAR-KIT - W/LUG

SQDPK23GTAL PK23GTAL 785901440895
39.66 / EA
http://schema.org/OutOfStock
Mayer-DDS-Load center accessory, QO/Homeline, ground bar kit, 23 terminals, with AWG 1-4/0 lug in aluminum or copper-1
  • Depth: 0.312 in
  • Warranty Length: 18 mth
By grounding the system, it helps prevent electrical shock hazards and ensures that stray electrical currents are safely directed to the earth. It acts as a centralized location where all ground wires from branch circuits are securely connected. It provides a neat and organized way to terminate multiple ground conductors, making the panel easier to inspect and maintain. This is a Ground Lug kit compatible for both QO and Homeline Load Center. It has 24 number of circuits which accepts 23-(1) 14 4 or (2) 14 or 12AWG copper or (1) 12 4 or (2) 12 or 10AWG aluminum and 1-(1) 1-4/0AWG..
QTY
  • Product Description
  • Features
  • Specifications
By grounding the system, it helps prevent electrical shock hazards and ensures that stray electrical currents are safely directed to the earth. It acts as a centralized location where all ground wires from branch circuits are securely connected. It provides a neat and organized way to terminate multiple ground conductors, making the panel easier to inspect and maintain. This is a Ground Lug kit compatible for both QO and Homeline Load Center. It has 24 number of circuits which accepts 23-(1) 14 4 or (2) 14 or 12AWG copper or (1) 12 4 or (2) 12 or 10AWG aluminum and 1-(1) 1-4/0AWG..
  • Features
    • QO/Homeline Load center provides superior performance and durability
    • Straight in wiring saves wire, labor, and time
    • Compatible with any Square D™ QO Circuit Breaker
    • The fully distributed neutral bar allows for QO™ plug-on neutral circuit breakers in any space
    • Complies with UL 67 listed, CSA, and IEC standards
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Physical Attributes
    • Bar Length : 240 mm
  • Complementary Attributes
    • Maximum Length Of Segment : 80 mm
  • Important Information Attributes
    • Persona Type Ids : EU, EUA, LC, OM, SC
    • Persona Type Names : End User, Consumer, Contractor, Original Equipment Manufacturer, Electrician
    • AWG Gauge : AWG 14...AWG 4 copper, AWG 12...AWG 4 aluminium, AWG 4...AWG 1 aluminium/copper
    • Tightening Torque : 25 lb.in, AWG 12...AWG 10, aluminium, 30 lb.in, mounting screw 30 lb.in, 20 lb.in, AWG 14...AWG 10, copper, 20 lb.in, AWG 12...AWG 10, aluminium, 35 lb.in, AWG 6...AWG 4, 25 lb.in, AWG 8, 25 lb.in, AWG 14...AWG 12, copper
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-13
    • Manufacturer : Schneider Electric
    • Legacy WEEE Scope : Out
    • Scope Perimeter : Outside of Europe
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : No
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : RESIDENTIAL
    • Market Segmentation : Residential
    • H And D Domain : Safety
    • H And D Subrange : RESI
    • H And D Enrichment Assignment : yes
    • H And D Enrichment Function : ACCESSORIES
    • H And D Enrichment Class 3 : Enclosures
    • H And D Enrichment Class 4 : Enclosure accessory
    • Energy Efficiency Optimized : False
    • Package Weight Lbs : 172 g
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : bar
    • Provided Equipment : 2 screw
    • Range Of Product : QO
    • Returnability : Yes
    • Sustainable Packaging : No
    • Medium Desc : Load center accessory, QO/Homeline, ground bar kit, 23 terminals, with AWG 1-4/0 lug in aluminum or copper
    • Stocking Flag : N
    • Product Kit Identifier : N
    • Global Commercial Status : Commercialised
  • Environment Attributes Main
    • China ROHS Regulation : Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
    • EU ROHS Directive : Compliant By Exemption , Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS Exemption Information : Yes
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • Mercury Free : Yes
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • General Attributes
    • Product Or Component Type : bar
    • Provided Equipment : 2 screw
    • Range Of Product : QO
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Depth : 0.312 in
