Load center accessory, QO/Homeline, ground bar kit, 15 terminals, with AWG 1-4/0 lug in aluminum or copper

LOAD CENTER EQUIPMENT GRD BAR

SQDPK15GTAL PK15GTAL 785901440871
34.11 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Load center accessory, QO/Homeline, ground bar kit, 15 terminals, with AWG 1-4/0 lug in aluminum or copper-1
  • Depth: 0.312 in
  • Warranty Length: 18 mth
By grounding the system, it helps prevent electrical shock hazards and ensures that stray electrical currents are safely directed to the earth. It acts as a centralized location where all ground wires from branch circuits are securely connected. It provides a neat and organized way to terminate multiple ground conductors, making the panel easier to inspect and maintain. This is a Ground Lug kit compatible for both QO and Homeline Load Center. It has 16 number of circuits which accepts 15-(1) 14 4 or (2) 14 or 12AWG copper or (1) 12 4 or (2) 12 or 10AWG aluminum and 1-(1) 1-4/0AWG aluminum or copper.
QTY
  • Product Description
  • Features
  • Specifications
By grounding the system, it helps prevent electrical shock hazards and ensures that stray electrical currents are safely directed to the earth. It acts as a centralized location where all ground wires from branch circuits are securely connected. It provides a neat and organized way to terminate multiple ground conductors, making the panel easier to inspect and maintain. This is a Ground Lug kit compatible for both QO and Homeline Load Center. It has 16 number of circuits which accepts 15-(1) 14 4 or (2) 14 or 12AWG copper or (1) 12 4 or (2) 12 or 10AWG aluminum and 1-(1) 1-4/0AWG aluminum or copper.
  • Features
    • QO/Homeline Load center provides superior performance and durability
    • Straight in wiring saves wire, labor, and time
    • Compatible with any Square D™ QO Circuit Breaker
    • The fully distributed neutral bar allows for QO™ plug-on neutral circuit breakers in any space
    • Complies with UL 67 listed, CSA, and IEC standards
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Physical Attributes
    • Bar Length : 207 mm
  • Complementary Attributes
    • Maximum Length Of Segment : 80 mm
  • Important Information Attributes
    • Persona Type Ids : EU, EUA, LC, OM, SC
    • Persona Type Names : End User, Consumer, Contractor, Original Equipment Manufacturer, Electrician
    • AWG Gauge : AWG 14...AWG 4 copper, AWG 12...AWG 4 aluminium, AWG 4...AWG 1 aluminium/copper
    • Tightening Torque : 25 lb.in, AWG 12...AWG 10, aluminium, 30 lb.in, mounting screw 30 lb.in, 20 lb.in, AWG 14...AWG 10, copper, 20 lb.in, AWG 12...AWG 10, aluminium, 35 lb.in, AWG 6...AWG 4, 25 lb.in, AWG 8, 25 lb.in, AWG 14...AWG 12, copper
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-13
    • Legacy WEEE Scope : Out
    • Scope Perimeter : At least in Europe
    • Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
    • Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : No
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : RESIDENTIAL
    • Market Segmentation : Residential
    • H And D Domain : Safety
    • H And D Subrange : RESI
    • H And D Enrichment Assignment : yes
    • H And D Enrichment Function : ACCESSORIES
    • H And D Enrichment Class 3 : Enclosures
    • H And D Enrichment Class 4 : Enclosure accessory
    • Energy Efficiency Optimized : False
    • Package Weight Lbs : 145 g
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : bar
    • Provided Equipment : 2 screw
    • Range Of Product : QO
    • Returnability : Yes
    • Sustainable Packaging : No
    • Medium Desc : Load center accessory, QO/Homeline, ground bar kit, 15 terminals, with AWG 1-4/0 lug in aluminum or copper
    • Stocking Flag : N
    • Product Kit Identifier : N
    • Global Commercial Status : Commercialised
  • Environment Attributes Main
    • China ROHS Regulation : Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
    • EU ROHS Directive : Compliant , Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS Exemption Information : Yes
    • Take Back : No
    • Reach Free SHVC : Yes
    • Recycled Metal Content At Cr Level : 0 %
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Free Of SVHC : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
  • General Attributes
    • Product Or Component Type : bar
    • Provided Equipment : 2 screw
    • Range Of Product : QO
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Depth : 0.312 in
