Load center interior, QO, mounting base, 3 phase, 3 spaces, 60A main lugs, OEM

OEM MOUNTING BASE 60A 3PH 3SP

SQDQON403L60N QON403L60N 785901107439
51.17 / EACH
http://schema.org/OutOfStock
Load center interior, QO, mounting base, 3 phase, 3 spaces, 60A main lugs, OEM
  • Depth: 48 mm
  • Height: 83 mm
  • Net Weight: 0.500 kg
  • Number of Spaces: 3
  • Short Circuit Current Rating: 10 kA
  • Warranty Length: 18 mth
  • Weight: 0.500 kg
  • Width: 107 mm
QO Load Centers offer premium features like QO breakers, ground arc fault interrupters and surge arresters. QO load centers are designed for residential and industrial use to protect electrical systems, equipment and people. Systems are single or three phase and have indoor and outdoor versions. QO Load Centers enable the use of a full complement of accessories. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This QO OEM plug on mounting base is for 60A 240 VAC 3 phase 4 wire systems. This QO OEM mounting base has a 10 kA breaking capacity. This product is for 3 spaces. This mounting base will accept only QO plug on circuit breakers. The lugs will accept a wire range of 12 AWG to 6 AWG copper or aluminum wire. QO OEM bases is UL component recognized.
QTY
  • Product Description
  • Features
  • Specifications
QO Load Centers offer premium features like QO breakers, ground arc fault interrupters and surge arresters. QO load centers are designed for residential and industrial use to protect electrical systems, equipment and people. Systems are single or three phase and have indoor and outdoor versions. QO Load Centers enable the use of a full complement of accessories. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This QO OEM plug on mounting base is for 60A 240 VAC 3 phase 4 wire systems. This QO OEM mounting base has a 10 kA breaking capacity. This product is for 3 spaces. This mounting base will accept only QO plug on circuit breakers. The lugs will accept a wire range of 12 AWG to 6 AWG copper or aluminum wire. QO OEM bases is UL component recognized.
  • Prop 65
    • "WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov"
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Packaging Made With Recycled Cardboard : No
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP2101006
    • Packaging Without Single Use Plastic : No
    • Toxic Heavy Metal Free : Yes
    • California Proposition 65 : "WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov"
    • Reach Free Of Svhc : Yes
    • China Rohs Regulation : Pro-active China RoHS declaration (out of China RoHS legal scope)
    • Circularity Profile : N/A
    • Take-Back : No
    • Eu Rohs Directive : Compliant
  • Complementary
    • Product Certifications : CSA || UL
    • Height : 83 mm
    • Net Weight : 0.500 kg
    • Awg Gauge : AWG 12...AWG 6 aluminium/copper
    • Width : 107 mm
    • Depth : 48 mm
  • Specifications
    • Country of Origin : Mexico
    • Width : 107 mm
    • Height : 83 mm
    • Weight : 0.500 kg
    • Phase : 3 phase 4 wires
    • Range Of Product : QO
    • [Ue] Rated Operational Voltage : 120/240 V AC
    • Product Or Component Type : mounting base
    • Number Of Spaces : 3
    • Short-Circuit Current : 10 kA
    • Line Rated Current : 60 A
    • Load Center Type : main lugs
  • Contractual warranty
    • Warranty : 18 months
