SQUARE D

Mini circuit breaker, E-Frame, 30A, 1 pole, 277 VAC, 65 kA max, bolt on

MINIATURE CIRCUIT BREAKER 277V

SQDEGB14030 EGB14030 785901311096
230.95 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, E-Frame, 30A, 1 pole, 277 VAC, 65 kA max, bolt on-2
  • Certifications: CULus
  • Depth: 4.05 in
  • Height: 5.66 in
  • Line Rated Current: 30 A
  • Mounting Type: Bolt-On
  • Net Weight: 2 lb
  • Number of Poles: 1
  • Warranty Length: 18 mth
  • Width: 0.98 in
E Frame thermal magentic circuit breakers are for use in NF panelboards. These circuit breakers will protect against overload and short circuit conditions. Breakers have a trip indicator. This bolt on circuit breaker has a maximum voltage rating of 277 VAC. This 1 pole 30 A breaker is rated for HACR and HID applications. Breaker has a breaking capacity of 35 kA at 277 VAC. Circuit breaker has other breaking capacity ratings based on operting voltage. The breaking capacity code for this circuit breaker is G. Electrical connections are made using aluminum lugs. The lugs on this circuit breaker will accept 14 AWG to 6 AWG copper and 12 AWG to 6 AWG aluminum wire. One space is used by this circuit breaker. Circuit breaker is 5.66 inches tall, is 0.98 inches wide and 4.05 inches deep. E frame circuit breakers are UL Listed and CSA certified.
QTY
  • Product Description
  • Specifications
E Frame thermal magentic circuit breakers are for use in NF panelboards. These circuit breakers will protect against overload and short circuit conditions. Breakers have a trip indicator. This bolt on circuit breaker has a maximum voltage rating of 277 VAC. This 1 pole 30 A breaker is rated for HACR and HID applications. Breaker has a breaking capacity of 35 kA at 277 VAC. Circuit breaker has other breaking capacity ratings based on operting voltage. The breaking capacity code for this circuit breaker is G. Electrical connections are made using aluminum lugs. The lugs on this circuit breaker will accept 14 AWG to 6 AWG copper and 12 AWG to 6 AWG aluminum wire. One space is used by this circuit breaker. Circuit breaker is 5.66 inches tall, is 0.98 inches wide and 4.05 inches deep. E frame circuit breakers are UL Listed and CSA certified.
  • Environment
    • Product Certifications : cULus
    • Ambient Air Temperature For Operation : 40 °C
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
  • Complementary
    • Height : 5.66 in
    • Holding Current : 270 A
    • Tightening Torque : 3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
    • Breaking Capacity Code : G
    • Product Destination : NF panelboard
    • Electrical Connection : lugs aluminium
    • Number Of Spaces Required : 1
    • Number Of Spaces : 1
    • Net Weight : 2 lb(US)
    • Circuit Breaker Application : HID rated || HACR rated
    • Mounting Mode : bolt-on
    • Line Rated Current : 30 A
    • Protection Type : short-circuit || overload
    • Local Signalling : trip indicator
    • Awg Gauge : AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
    • Width : 0.98 in
    • Depth : 4.05 in
    • Breaking Capacity : 35 kA 277 V AC || 35 kA 240 V AC || 65 kA 120 V AC || 35 kA 120/240 V AC
    • Trip Unit Technology : thermal-magnetic
    • Number Of Poles : 1
    • [Ue] Rated Operational Voltage : 277 V AC
  • Specifications
    • Module Type : E-Frame
    • Range Of Product : 125 A Frame EDB-EGB-EJB
    • Trip Unit Rating : 875-875 A
    • Product Or Component Type : miniature circuit-breaker
    • Device Short Name : EGB
