Automatic switch, PowerPacT H, 150A, 3 pole, 600VAC, 18kA, lugs, magnetic

AUTOMATIC SWITCH, POWERPACT H,

SQDHGP36000S15 HGP36000S15 785901643425
1697.55 / EA
http://schema.org/OutOfStock
Mayer-DDS-Automatic switch, PowerPacT H, 150A, 3 pole, 600VAC, 18kA, lugs, magnetic-1
  • Country of Origin: USA
  • Depth: 4.36 in
  • Height: 6.4 in
  • Warranty Length: 18 mth
  • Width: 2.12 in
PowerPacT H-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection possibilities as the H-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. The automatic switch can make and break its rated current. PowerPacT H-Frame switches are available in unit mount, I-Line, plug in, or drawout constructions. This switch is unit mount and has lugs on the load side and terminal nuts on the line side. This PowerPacT H, 150A, 3 pole, automatic switch has a short circuit withstand current rating of 18kA at 600VAC. PowerPacT H automatic switches comply to UL, CSA, ANCE, and IEC standards.
QTY
  • Product Description
  • Features
  • Specifications
PowerPacT H-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection possibilities as the H-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. The automatic switch can make and break its rated current. PowerPacT H-Frame switches are available in unit mount, I-Line, plug in, or drawout constructions. This switch is unit mount and has lugs on the load side and terminal nuts on the line side. This PowerPacT H, 150A, 3 pole, automatic switch has a short circuit withstand current rating of 18kA at 600VAC. PowerPacT H automatic switches comply to UL, CSA, ANCE, and IEC standards.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Environment
    • Product Certifications : CE || IEC || NMX || UL Listed || CCC || CSA
  • Contractual warranty
    • Warranty : 18 months
  • Environmental data
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP2206027EN
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Circularity Profile : ENVEOLI2206027EN
    • Take-Back : No
    • Pvc Free : Yes
    • Global Warming ; Total Life Cycle​ : 952 kg CO2 eq.
    • Eu Rohs Directive : Compliant with Exemptions
    • Carbon Footprint (Kg Co2 Eq, Total Life Cycle) : 951.5423547636
  • Complementary
    • Terminal Identifier : AL150HD
    • Height : 6.4 in
    • Breaking Capacity Code : G
    • Magnetic Tripping Current : 2250-2250 A
    • Mounting Mode : unit mount
    • Poles Description : 3P
    • Line Rated Current : 150 A
    • Width : 2.12 in
    • Depth : 4.36 in
  • Specifications
    • Country of Origin : United States
    • Width : 2.12 in
    • Height : 6.4 in
    • Range Of Product : PowerPact H
    • Product Or Component Type : automatic switch
    • Trip Unit Technology : magnetic
