Automatic switch, PowerPacT B, 125A, 3 pole, 600Y/347VAC, 14kA, EverLink lug, magnetic

AUTOMATIC SWITCH, POWERPACT B,

SQDBDL36000S12 BDL36000S12 SQDBDL36000S12
497.28 / EA
http://schema.org/OutOfStock
  • Country of Origin: Mexico
  • Depth: 3.5 in
  • Height: 5.39 in
  • Width: 3.19 in
PowerPacT B-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction to, use the same accessories, and offer the same connection pos
QTY
  • Product Description
  • Features
  • Specifications
PowerPacT B-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction to, use the same accessories, and offer the same connection pos
  • Mounting Mode
    • clip-on 35 x 15 mm symmetrical DIN rail)
    • by screws plate)
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Mechanical Durability
    • 15000 cycles IEC 947-1 Annex K ed 5.2
  • Carbon Footprint Of The Installation Phase A5
    • 0.3750538465236933
    • 0.4 kg CO2 eq.
  • Carbon Footprint Of The End Of Life Phase C1 To C4
    • 2 kg CO2 eq.
    • 2.1893161478477783
  • Ue Rated Operational Voltage
    • 600Y/347 V AC 50/60 Hz UL 489
  • Electrical Connection
    • Everlink lug, line
    • Everlink lug, load
  • Carbon Footprint Of The Manufacturing Phase A1 To A3
    • 7 kg CO2 eq.
    • 6.8801551049160405
  • Electrical Durability
    • 10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
  • Market Segmentation
    • Commercial
    • Industrial
  • Persona Type Names
    • End User
    • Contractor
    • Original Equipment Manufacturer
    • OEM - Control Panelbuilder
    • Panel Builder
    • Electrician
    • System Integrator
  • Carbon Footprint Of The Use Phase B2 B3 B4 B6
    • 326 kg CO2 eq.
    • 325.86084321646615
  • Number Of Slots
    • 1 auxiliary switch OF plug-in)
    • 1 voltage release MN or MX plug-in)
    • 1 voltage release MN o
  • Persona Type Ids
    • EU
    • LC
    • OM
    • OM8
    • PB
    • SC
    • SI
  • Short Circuit Withstand
    • 25 kA 208Y/120 V UL 489
    • 25 kA 240 V UL 489
    • 18 kA 480Y/277 V UL 489
    • 18 kA 480 V UL 489
    • 18 kA 480 V UL
  • Carbon Footprint Of The Distribution Phase A4
    • 0
    • 0 kg CO2 eq.
  • Tightening Torque
    • 5-5 N.m 2.5-10 mm²
    • 9-9 N.m 16-95 mm²
  • Operating Altitude
    • 6561.68 ft (2000 m) without derating
    • 5000 m with derating
  • AWG Gauge
    • AWG 6...AWG 2/0 fine stranded aluminium/copper
    • AWG 14...AWG 3/0 rigid or stranded aluminium/copper
    • AWG 14...
  • Market Segmentation Id
    • COMMERCIAL
    • INDUSTRIAL
  • Color
    • Gray RAL 7016)
  • Local Signalling
    • flag (green) for presence of auxiliary contacts
  • Physical Attributes
    • Wire Stripping Length : 20 mm
  • Conformance Attributes
    • Product Certifications : UL
    • Standards : UL 489
  • Complementary Attributes
    • Line Rated Current : 125 A
  • Important Information Attributes
    • Country Id : US
    • B2B Bullet Point 1 : To open and close a circuit under normal operating conditions
    • B2B Bullet Point 2 : Can make and break its rated current
    • B2B Bullet Point 3 : Factory set nonadjustable trip point to protect the molded case switch
    • B2B Bullet Point 4 : A wide range of accessories, auxiliaries, and lug connections available
    • B2B Bullet Point 5 : UL and CSA certified
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-09-17
    • Device Type : LV equipment - LV switch - disconnector
    • Serviceability : No
    • Traceability : Yes
    • Field Service Division : PPIBS
    • Average Life Duration : 15 year(s)
    • Manufacturing Carbon Footprint : 6.88015510491604
    • Distribution Carbon Footprint : 0
    • Installation Carbon Footprint : 0.375053846523693
    • Use Carbon Footprint : 325.860843216466
    • End Of Life Carbon Footprint : 2.18931614784778
    • Legacy WEEE Scope : In
    • WEEE Product Category : 5
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : No need of specific recycling operations
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS Eur In Scope : Yes
    • ROHS Eur Status : Compliant with Exemptions
    • ROHS Eur Conformity Date : 1909
    • ROHS Eur Full Compliance Status : Compliant with Exemptions
    • ROHS Eur Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
    • China ROHS In Scope : No
    • Green Premium Status For Reporting : Green Premium product
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
    • Tier Id : 1
    • Tier : 1
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Connection Pitch : 27 mm
    • Contact Position Indicator : yes
    • Control Type : toggle
    • Device Application : distribution
    • Halogen Free Status : Halogen free product
    • Magnetic Hold Current : 880 A
    • Magnetic Tripping Current : 1320-1320 A
    • Package Weight Lbs : 1.325 kg
    • Poles Description : 3P
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : automatic switch
    • Quality Labels : CE
    • Quantity Per Set : set of 1
    • Range : PowerPact
    • Returnability : Yes
    • Sustainable Packaging : Yes
    • Total Lifecycle Carbon Footprint : 335 kg CO2 eq.
    • Carbon Footprint Kg Co2 Eq Total Life Cycle : 335.30536831575364
    • Relationshiptype : Compatible relationship
  • General Attributes
    • Product Or Component Type : automatic switch
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=466987634&lang=en-us
    • Take Back : No
    • Halogene Performance : Halogen free product
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • Carbon Footprint : 335.305368315754
    • 9 MM Pitches : 9
    • Ambient Air Temperature For Operation : -25-70 °C
    • Ambient Air Temperature For Storage : -50-85 °C
    • Environmental Disclosure : ENVPEP2311047_V2
    • Eu Rohs Directive : Compliant with Exemptions
    • Halogen Content Performance : Halogen free product
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • Specifications
    • Country of Origin : Mexico
    • Height : 5.39 in
    • Width : 3.19 in
    • Depth : 3.5 in
