  • Features
    • LCD graphics display — Text and mimic diagrams that display modes of operation, system parameters and alarms.
    • PowerChute Personal Edition OS Compatibility — This software supports numerous operating systems and processors
    • Battery replacement without tools — Enables fast battery replacement, lowering Mean Time to Repair (MTTR).
    • Battery and surge protected outlets — Back up and protect your hardware and data during power outages, surges and spikes.
    • USB charging ports — Simultaneously charge mobile devices, including smartphones and tablets.
    • Battery backup and surge protection — Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
    • ENERGY STAR for UPS — Establishes that the efficiency of the UPS is in the top 25% of the market as verified by third party testing
    • RoHS — Certifies that electronic devices don't contain hazardous metals and flame retardants
    • EMI and RFI noise filtering — Reduces line noise that can cause data loss and keyboard errors.
    • Audible alarms — Provides notification of changing utility power and UPS power conditions
    • Automatic self-test — Periodic battery self-test ensures early detection of a battery that needs to be replaced.
    • Boost Automatic Voltage Regulation (AVR) — Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
    • Dataline surge protection — Provides protection of connected equipment from power surges on the data lines.
    • Hot-swappable batteries — Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
    • Lifetime data recovery warranty — Provides peace of mind by providing professional data recovery services in the event data is lost due to the failure of the unit.
    • Building Wiring Fault Indicator — This LED informs users of potentially dangerous wiring problems in the wall circuit.
  • Conformance
    • Approvals : ENERGY STAR V2.0 (USA), NOM, TUV C-US certified
    • EquipmentProtectionPolicy : Lifetime : $250000
  • Battery
    • ReplacementBattery : APCRBC161
    • TypicalRechargeTime : 16 h
    • BatteryType : Lead-Acid battery
  • Sustainability
    • Rohs : Compliant with Exemptions
    • Reach : Reference contains Substances of Very High Concern above the threshold
    • OptimizedEnergyEfficiency : Energy efficient product
    • TakeBack : Yes
    • MercuryFree : Yes
  • Weight, Height, Width, Depth
    • Weight : 25.13 lb(US) (11.4 kg)
    • Height : 10.24 in (26 cm) in
    • Width : 3.94 in (10 cm) in
    • Depth : 14.49 in (36.8 cm) in
  • Physical
    • ProductOrientation : no preference
    • Color : Black
    • SurgeEnergyRating : 1080 J
  • Input
    • CordLength : 6 ft (1.83 m)
    • InputConnectionType : NEMA 5-15P
    • InputVoltage : 120 V
  • Output
    • OutputPowerCapacity : 1500 VA
    • OutputConnections : 6 NEMA 5-15R, 4 NEMA 5-15R surge
    • NominalOutputVoltage : 120 V
    • Topology : Line Interactive
    • Waveformtype : Stepped approximation to a sinewave
  • Warranty
    • Warranty : 3 years repair or replace
